Figure 5-20 Installing the Outdoor Sensor to the vertical unistrut
34
Vertical unistrut
46
Bolt
47
Washer
NOTE:
Figure 5-21, page 41
Switch Enclosure, Plenum Sensor, and Outdoor Sensor. This information can also be found on
the outside of each component.
Figure 5-21 Switch and sensors - electrical specification
PNEG-2347 Cable Monitoring System
shows the electrical specifications for the Plenum and Outdoor Sensor
Chapter 5: Installing the Power Supply
Spring nut
48
Outdoor Sensor mounting bracket
49
41
