Chapter 3: Cable Monitoring Overview

System Overview

The parts list below outlines the primary components of the Cable Monitoring System.
Figure 3-1 Cable Monitoring parts identification
Table 3-1 Cable Monitoring parts list
Ref Number
16
17
18
19
20
21
22
23
24
25
1 Part Number will vary depending on the use of AC vs. DC relays in the Fan Control Module.
2 Part Number will vary depending on the bin size.
3 Quantity will vary depending on number of T/RH cables in the bin.
24
Part Number
074-11954
028-00846
074-1188A 1
511-0071B 2
074-11957
511-0041C 2
074-11955
511-0042D 2
074-11956
511-0042E 2
Description
Cable Monitoring Hub
Mounting Bracket
Fan Control Module
Cable Hub to Fan Control Module Cable
Power Supply Unit
Cable Hub to Power Supply Unit Cable
Mux Whip
Dual Connector T/RH Extension Cable
Mux Box
Single Connector T/RH Extension Cable
Quantity
PNEG-2347 Cable Monitoring System
1
1
1
1
1
1
1
X 3
1
X 3
