12
SET MODE

DV Set

RX Bass
[MENU] > SET > DV Set > Tone Control > RX Bass
Selects the receive audio bass filter level�
• Cut: Reduces low frequencies�
• Normal: Normal tone balance�
• Boost: Increases low frequencies�
RX Treble
[MENU] > SET > DV Set > Tone Control > RX Treble
Selects the receive audio treble filter level�
• Cut: Reduces high frequencies�
• Normal: Normal tone balance�
• Boost: Increases high frequencies�
RX Bass Boost
[MENU] > SET > DV Set > Tone Control >
RX Bass Boost
Turns the Receive Audio Bass Boost function ON or
OFF�
L This function is different from the "Boost" setting of "RX
Bass�"
• OFF: Turns OFF the function�
• ON: This function boosts the receive audio bass�
TX Bass
[MENU] > SET > DV Set > Tone Control > TX Bass
Selects the transmit audio bass filter level�
• Cut: Reduces low frequencies�
• Normal: Normal tone balance�
• Boost: Increases low frequencies�
TX Treble
[MENU] > SET > DV Set > Tone Control > TX Treble
Selects the transmit audio treble filter level�
• Cut: Reduces high frequencies�
• Normal: Normal tone balance�
• Boost: Increases high frequencies�
(Default: Normal)
(Default: Normal)
(Default: OFF)
(Default: Normal)
(Default: Normal)
12-10
Auto Reply
[MENU] > SET > DV Set > Auto Reply
Selects an option for the Automatic Reply function in
the DV mode� This function automatically replies to a
call addressed to your own call sign (MY), even if you
are away from the transceiver�
• OFF: Turns OFF the function�
• ON: Replies with your own call sign (MY)�
(No audio reply is sent)
• Voice: Replies with your call sign (MY) and any
Auto Reply message recorded on the
microSD (up to 10 seconds)�
L The transmitted audio can be monitored�
L If no microSD card is inserted, or no
message is recorded, only your call sign is
transmitted�
• Position: Replies with your own call sign and
transmits your position data using the
internal GPS receiver�
L When "GPS Select" is set to "OFF" or
"Manual," the internal GPS receiver is
temporarily turned ON�
L When "ON" or "Voice" is selected, the Automatic Reply
function is automatically turned OFF when you push
[PTT]� When "Position" is selected, the Automatic Reply
function is not turned OFF, even if you push [PTT]�
DV Data TX
[MENU] > SET > DV Set > DV Data TX
Selects whether to manually or automatically transmit
data in the DV mode�
• PTT: Push [PTT] to manually transmit data�
• Auto: When data is input from a PC through the
[USB] port, the transceiver automatically
transmits it�
Fast Data
[MENU] > SET > DV Set > DV Fast Data > Fast Data
Selects whether or not to use the DV Fast Data
function for data communication in the DV mode�
The DV Fast Data function uses the data and the
audio frames to send data approximately 3�5 times
faster than the normal speed� So, no audio can be
sent�
• OFF: Sends data at a slow speed
(approximately 950 bps)�
• ON: Sends data at a fast speed
(approximately 3480 bps)�
L Even if "ON" is selected, when you push [PTT], the data
is sent at the slow speed, because the audio frame is
used for the audio transmission�
L The GPS data speed is set in "GPS Data Speed�"
(Default: OFF)
(Default: Auto)
(Default: OFF)
