Shining 3D EinScan-Pro+ User Manual page 26

Auto Scan
preview windows for Manual align, As shown on the right.
Delete Current Data
If you are not satisfied with current scanning data, or there is not enough overlapping
region for registration, click the button to delete current data and then change the position of the
scanner or the object to scan again.
When auto scan mode is scanning, you can click the button to stop the current scan. The
current data will be deleted directly.
Note：
When import project, click
is remove the single data; Auto scan is to delete all the data.
Pause
Click the button, scanning will pause; Click again to resume scanning.
Mesh
When the scan is completed, click the botton, proceed to post-processing. You will see
two modes after clicking the button: Watertight and Unwatertight. Watertight usually slower
than unwatertigt. Texture scan mode will take more time compared to Non-Texture scan mode.
Watertight
Closed model can be printed directly. After choose this mode, you should select the
object details.
Select High for objects with fine texture, select Med or Low for objects in smooth
surface or with less detail. The time for data processing is in relation to the detail setting. The
higher the level of details is, the longer time the processing takes. It may keep for a long time in
95%, please be patient.
Select the object details：
Unwatertight
Unclosed model. The following picture is the watertight and unwatertight model.
button the fixed scan ( without turntable )
25
