Shining 3D EinScan-Pro+ User Manual page 25

Auto Scan
excess parts, both data and mark points can be edited.
SHIFT+Left mouse： Select excess parts, the selected section is displayed in red, as shown below.
Delete selected data
Click the button and "DELETE" in the keyboard to delete
selected data.
Undo
You can only undo the last deleted data.
Show/Hide Stripes
Click the button to switch the texture display and hide. Non-texture scan,
there is no such button.
End single-piece edit
Click to save data and exit the single-piece
edition; Click , delete the current scan dat.
After end the single-piece edit, the right toolbar will
display, and now can edit the whole scan data. The
specific operation is the same as the single-piece edit.
Manual Align
If automatic alignment failed during scanning,
you can use manual align. Click the button to open
Manual Align view port on the left side of the software.
Keep SHIFT down, and click left mouse button to select
at least 3 non-collinear corresponding points in the 3D
24
