Shining 3D EinScan-Pro+ User Manual page 24

Auto Scan
Work distance：Adjust the distance between the object and device
450 ~ 550mm), until the cross is clearly to be seen on the object.
appropriate at the right scan distance: equipment against objects, the cross is clearly in the
brightness viewing window.
per round under turntable scan. The default setting is 8 times.
Align Mode
The default is turntable coded targets align mode，you can also choose
markers, feature or global mark point align mode. Align mode can be
re-selected after the turntable has rotated one circle.
If you import global markers point file when creating a new project, the align mode is global
mark point, and the project cannot change to other align mode. In the new project interface,
select
Import global mark point as shown below. Note：The use of global markers point, the only point
in the framework can scan.
Note：
1. Choose turntable coded targets align mode, Please make sure that the object won't
block the coded targets on the turntable. Or, there will be no fringe pattern, while
turntable will be still rotating. If the scanned object is too high and will block the
coded target on turntable, you can stick mark points on it (if allowed) to continue
auto scan. At this time, please make sure that the coded target on the turntable are
covered, so as not to affect the scanning. Make sure that in each single scan area
has at least 4 points. Refer to
2. Feature align, when scan it will verifying and scan 3 piece of data.
HDR
Enable HDR brightness can scan bright and dark objects.
Start Scan
Click the button to start scanning. After the turntable has rotated one circle，you can
change turntable steps and align mode.
Edit buttons: ① Deselect ② Revert ③ Delete ④ Undo⑤ Show/Hide
Stripes
You can edit the current part data after each scan. You can do the below edition if the data has
Adjust Brightness
Drag the button to adjust the brightness. The brightness is
Turntable Steps
Before scanning, you can set the scan times
, can import three formats as asc, txt and p3.
Scan Preparation.
(suitable working distance is
23
