5.2.4 Installing the Rear Housing
1.
Place the rear housing properly and apply 3 x M8 screws at each side as shown in the diagram.
Figure 46: Place the rear housing
DANGER:
Screws must be properly tightened when using this product. Improper tightening may cause
the tool or part to fall out, or even cause personal injury and death.
TM Palletizing Operator User's Manual Product Version: 1.0 / Document Version: 1.0
82
