For your convenience, each slot is marked with the supported SIC types. For example, in Figure 1-1, SIC SLOT 3
supports Type A, Type B, Type C, and Type E SIC cards. SIC SLOT 2 supports Type A, Type B, Type C and Type E SIC
cards.
Figure 1-1 SIC Types Marked Above the SIC SLOT 3 and SLOT 2
Figure 1-2 Part of Back Panel of the RSR10-02E Series Routers

Technical Specifications

Table 1-3 Technical Specifications of the RSR10-02E Router
Model
Interfaces
SIC Slots
Processor
BOOT ROM
NAND FLASH
DDR II
Input Voltage
RSR10-02E
1 Console port
1 AUX port
1 USB interface
1 SD card interface
1 FUNC button
8 10/100 Mbps Ethernet ports
2 Gigabit Ethernet ports
2
Note: You can configure up to two SIC modules as required.
RISC
2 MB
128 MB
512 MB
100 VAC to 240 VAC, 50 Hz to 60 Hz
