Power Supply; Technical Specifications - Ruijie Reyee RG-EG105GWT Hardware Installation And Reference Manual

Hardware Installation and Reference Guide
Table 1-3 LED Specifications
No. LED
1 MESH LED
(White)
2 SYS LED
(Blue)
1.2.3

Power Supply

The RG-EG105GW(T) router adopts the power adapter (12 V/1.5 A) delivered with the device.
1.3

Technical Specifications

Table 1-4 Technical Specifications
RF Design
Transport Protocols
Status
Off
Flashing
alternately
Three bars on
Two bars on
One bar on
Flashing
Solid on
Off
Dual-stream and dual-radio
Compliant with 802.11ac wave2/wave1 and 802.11a/b/g/n simultaneously.
4
Description
1. Mesh pairing is not implemented.
2. Wireless relay is not set up.
Mesh pairing is in progress.
1. The Mesh signal strength is high.
2. The wireless relay signal strength is high.
1. The Mesh signal strength is medium.
2. The wireless relay signal strength is
medium.
1. The Mesh signal strength is low.
2. The wireless relay signal strength is low.
Fast flashing (at 8 Hz): The router is
starting up.
Slow flashing (at 0.5 Hz): The network is
unreachable.
One long flash followed by three short
flashes (at 0.8 Hz): The router is faulty.
Flashing twice in succession (at 0.8 Hz):
1. The router is restoring factory settings.
2. The router is upgrading the software.
Note: Do not power off the router in this case.
The router is functioning properly.
The router is not powered on.
Product Overview
