Indicator
Link
RDY
Features
The following table describes the basic features:
Table 1-29 Specifications of the SIC-1CE1 Card
Number of Ports
Interface Type
Cables
Standard Compliance
Operating Temperature:
Humidity
EMC
Cables
The following types of cables are provided:
Balanced cable with the RJ-45 plug: One end is the DB9 male connector, and the other end is the RJ-45 plug. The
characteristic impedance of the cable is 120Ω.
Balanced cable with the RJ-45 jack: One end is the DB9 male connector, and the other end is the RJ-45 jack. The
characteristic impedance of the cable is 120Ω.
Non-balanced cable: One end is the DB9 male connector, and the other end is attached with two male BNC connectors.
The characteristic impedance of the cable is 75Ω.
The cables are customer supplied.
SIC-SEC
SIC card model: SIC-SEC
Image and Indicators
The following figure shows the image of a Ruijie IPSec SIC with the key encryption function.
Figure 1-35 SIC-SEC
Status Meaning
Solid on The upper link has been established.
Off Failed to establish the upper link.
On Initialization completed.
Off Initialization failed.
One
DB9 female connector
Balanced cables or non-balanced cables
ITU-T G.703
Operating temperature: 0°C to 45°C
Storage temperature: -40°C to 70°C
Operating humidity: 10%–90% RH
EMI: GB 9254-2008 Class A
EMS: GB/T 17618-1998
