Features
The following table describes the basic features:
Table 1-15 Specifications of the SIC-1B-U Card
Number of Ports
Interface Type
Cables
Standard Compliance
Temperature:
Humidity
EMC
Table 1-16 Specifications of the SIC-1B-S/T Card
Number of Ports
Interface Type
Cables
Terminal Resistance
Standard compliance
Operating Temperature:
Humidity
EMC
Cables
The SIC-1B-U module uses standard telephone cables.
The SIC-1B-S/T module uses standard ISDN S/T cables or RJ-45 to R-J45 straight-through cables.
The cables are customer supplied.

SIC-1E1- F Interface Card

SIC card model: SIC-1E1-F
Image and Indicators
The following figure shows the image of a 1-port non-channelized E1 card (SIC-1E1-F).
Figure 1-22 SIC-1E1-F
One
RJ-45 port (compatible with RJ-11)
Telephone cable
ITU-T I.430,Q.921,Q.931
Operating temperature: 0°C to 45°C
Storage temperature: -40°C to 70°C
Operating humidity: 10% to 90% RH
EMI: GB 9254-2008 Class A
EMS: GB/T 17618-1998
One
RJ-45
ISDN S/T cables
Built-in 100Ω
ITU-T I.430,Q.921,Q.931
Operating temperature: 0°C to 45°C
Storage temperature: -40°C to 70°C
Operating humidity: 10% to 90% RH
EMI: GB 9254-2008 Class A
EMS: GB/T 17618-1998
