  • Page 1 RG-RSR77 Series Router Installation and Initialization...
  • Page 2 Contents ■ Device Installation ■ Initialization Configuration...

  • Page 3: Revision History

    For more detail configuration , see configuration guide for each product . you can download configuration guide at http://www.ruijienetworks.com For more technical enquiry , you can visit Ruijie Service portal at http://case.ruijienetworks.com . You need to sign up before submit a case.
  • Page 4 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables Safety Notes ① Do not install the devices in a wet place and keep them away from liquid. Keep routers away from heat sources. ②...
  • Page 5 Do not install the device with brute force. ③ The RG-RSR77 series routers are very heavy and they should be installed at the bottom of cabinets. ④ It is recommended that you install an empty chassis in the cabinet first and then install line cards.
  • Page 6 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables There Is a Ground Bar in the Installation Environment (Recommended) ① Remove the ground screw from the rear panel of the device.
  • Page 7 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables Connection Cable Requirements ① AC power: 100-240 V~/50-60 Hz ② The power cable is a 3-wire cable. It is recommended that the single-phase three-wire socket with neutral-point connector or multi-functional microcomputer power socket be used.
  • Page 8 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables Installing the Supervisor ① Operators should face the front panel of the router. Align the router supervisor with the opening edge of the supervisor slot on the front panel of ②...
  • Page 9 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables Installing Cards ① Operators should face the front panel of the router. ② Align a router card with the opening edge of the service slot on the front panel of the router.
  • Page 10 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables Card Installation Notes ① Before installing a router card, check the ID of the slot for accommodating the card. Do not insert it into the M1 or M2 slot.
  • Page 11 Hardware Installation Installing the Grounding Installing the Chassis to a Power-on Preparations Supervisor Specified Connecting Check and Cards Position Cables 1. Checking Whether Status Indicators Are Normal ① Focus on whether fans and cards can be identified correctly, whether power modules are powered on successfully, and the status of the active and standby supervisors.
  • Page 12 Getting Help ■ Hardware Installation ■ Initialization Configuration...
  • Page 13 Initialization Configuration  Recommended Initialization Configuration of the Device  Host name (recommended): • Ruijie(config)#hostname XWRJ • XWRJ(config)#  Interface description (recommended): • XWRJ(config)#interface f0/0 • XWRJ(config-if-FastEthernet 0/0)#description To_BJ  System clock (mandatory): The system time is very import. Fault logs or CA certificate implementation relies on time stamps.
  • Page 14 If this function is not configured, a fault that arises can be handled only at site. • XWRJ(config)#enable secret 0 ruijie //The enable password must be configured if the telnet function is configured. • XWRJ(config)#lin vty 0 4 •...

  • Page 15: Obtaining Help

    Obtaining Help Self-service • Official website of Ruijie Networks: www.ruijienetworks.com • Downloading of software and documents: www.ruijienetworks.com/service.aspx ftp: //partnetportal.ruijienetworks.com Remote technical support • Fault submission: case.ruijienetworks.com • Live Chat(Skype): service_rj@ruijienetworks.com...
