Led Indicators - Ruijie RG-RSR10-02E Series Hardware Installation And Reference Manual

Note: 1: FE1/0 to FE1/7 indicator
2: FE1/0 to FE1/7 port
3: GE0/0 to GE0/1 port
4: GE0/0 to GE0/1 port indicator
5: Console port
6: Aux ports
7: SD card interface
8: SD indicator

LED Indicators

Table 1-4 LED Indicators on the RSR10-02E Router
Indicator Status
Off
Blinking green
SYS
Solid green
Solid red
Off
PWR
Solid green
Off
SD
Green on
Blinking green
Solid red or blinking red
USB
Green on
Blinking green
Off
FE Port Solid green
Blinking green
9: USB interface
10: FUN button
11: PWR indicator, SYS indicator, USB indicator
12: Ruijie Networks RSR10 Series logo
Meaning
The router is not receiving power.
The router starts up.
The router is operational.
The router is not working properly.
Power off.
Power on.
SD card is not present.
SD card is connected to the device and is recognized.
SD card is receiving or transmitting data.
SD card is not working properly.
USB device is connected to the device and is recognized.
USB device is receiving or transmitting data.
No link.
FE port link up at 10/100 Mbps.
FE port link up at 10/100 Mbps, and is receiving or transmitting data.
