USB Port
LED Indicator
For descriptions of USB port indicator, see the "LED Indicators" section.
Features
The RSR10-02E series router provides one fixed USB port, through which the user can read configurations from the USB
device, or save configurations to the USB device.
Table 1-10 Specifications of the USB Port
Index
Interface Standard
Connector
Rate
Interface Type
Hot Swapping
The hot swapping for the USB device must strictly follow the "Configuring Reliability" chapter in the related
software configuration guide. For the avoidance of system abnormality, hot swapping is not allowed unless
the command for unplugging the USB is entered.
The USB device here refers to USB flash disks.
Cables
If you connect a USB device with a USB extension cable, the cable must be less than 5 meters.

SD Card Slot

LED Indicator
For descriptions of SD card indicator, see the "LED Indicators" section.
Features
The RSR10-02E series router provides one fixed SD card slot, through which the user can read configurations from an SD
card, or save configurations to the SD card.
Table 1-11 Specifications of the SD Card Slot
Index
Interface Standard
Connector
Parameters
USB 2.0
USB Host
1.5 Mbps, 12 Mbps, 480 Mbps
Host
Supported
Parameters
SD/SDHC
SD connector, 1 FUNC button
