Sic-3G-Td Interface Card; Image And Indicator - Ruijie RG-RSR10-02E Series Hardware Installation And Reference Manual

The following table describes panel indicators.
Table 1-30 LED Indicator on the SIC-SEC Card
Indicator
RDY
Features
The following table describes the basic features:
Table 1-31 Specifications of the SIC-SEC Card
Number of Ports
Interface Type.
Cables
Function Description
Operating Temperature
Humidity
EMC
Cables
The cables are not supplied with the router.

SIC-3G-TD Interface Card

SIC card model: SIC-3G-TD

Image and Indicator

The following figure shows the image of an SIC-3G-TD interface card.
Figure 1-36 SIC-3G-TD
Status Meaning
On Initialization completed.
Off Initialization failed.
None
N/A
N/A
The module encrypts keys and enables the encryption algorithm.
Operating temperature: 0°C to 50°C
Storage temperature: -40°C to 70°C
Operating humidity: 10% to 95% RH (non condensing)
EMI: GB 9254-2008 ClassA
EMS: GB/T 17618-1998
