7
NXDN™ OPERATION
Displaying the Call log
D The received Call log (Continued)
<Key operation>
You can display all received logs with the key
operation.
Using [Digital Button]:
1. Push [Digital Button] to enter the Application
Selection mode.
• The current call type is briefly displayed, then "VOICE"
is displayed.
2. Push [CH Up] or [CH Down] to select "CALL
LOG," then push [Digital Button].
Portable
CALL LOG
MENU DIGI ZONE SET DIGI
Mobile
C A L L L O G
• Enters the Destination ID Selection mode.
3. Push [CH Up] or [CH Down] to view the log.
Portable
VOICE
Station1
MENU DIGI ZONE SET DIGI
Mobile
V O I C E
S t a t i o n 1
L"NO LOG" is displayed when the memory has no log.
4. Hold down [Digital Button] for 1 second to return
to the Standby mode.
7-36
