7
NXDN™ OPERATION
Transmitting a call
D Directly entering a message
<Key operation>
Using [Digital Button]:
1. Push [Digital Button] to enter the Application
Selection mode.
• The current call type is briefly displayed, then "VOICE"
is displayed.
LTo change the call type, see page 7-3.
2. Push [CH Up] or [CH Down] to select "MSG," then
push [Digital Button].
Portable
MSG
MENU DIGI ZONE SET
Mobile
M S G
• Enters the Message Selection mode.
3. Push [CH Up] or [CH Down] to select the
message, then push [#] to enter the Message
Entry mode.
Portable
MSG
Hello!
MENU DIGI ZONE SET
Mobile
M S G
H e l l o !
• The first character blinks.
L In the Message Entry mode, the last character blinks
when [M] is pushed.
(Continued)
7-18
4. Enter a message of up to 100 characters.
Portable
MSG
Thank you!
MENU DIGI ZONE SET
Mobile
M S G
T h a n k y o u !
Innormation
L
• You can enter the following characters by pushing the
keypad one or more times.
Key Characters
0 . ! ? ' " ,
[0]
(space)
1 # . /
[1]
2 A B C a b c
[2]
3 D E F d e f
[3]
4 G H I g h i
[4]
5 J K L j k l
[5]
[6] 6 M N O m n o
7 P Q R S p q r s
[7]
8 T U V t u v
[8]
[9] 9 W X Y Z w x y z
• To move the cursor, push [M] or [#].
• To enter a space, push [CH Up].
• To delete, push [CH Down].
• To delete all, hold down [#] for 1 second.
• To cancel, push [dPMR Button].
5. After entering a message, hold down [dPMR
Button] for 1 second to save the message.
6. Push [dPMR Button] to enter the Destination ID
Selection mode.
7. Push [CH Up] or [CH Down] to select the
destination ID.
8. Push [PTT] to transmit the entered message to
the selected station or Talkgroup.
• "MSG OK" is displayed after receiving an
acknowledgement from the target station.
• "MSG FAIL" is displayed if the target station does not
send back an acknowledgement.
; : _ ( ) < > [ ]
+ – = \ & % $ @ ^
