13.6.10 Fault Signalization

The system is protected against failure states, by stopping and braking the drive system, and respective signalization. The fault
indicator flashing briefly and the accumulator indicator shows the fault state. Some defects are cleared automatically (e.g.: drive
overheating).
Error
Drive overheated*
Electronics overheated*
Brake error
Retraction not completed
5V off limits
FETclosingpenetrated
Control circuit overheated
Controlcircuiterror
Activation button stuck
Retraction button stuck
Activebuttonafterstart
* An acoustic signal occurs before the drive is blocked (short acoustic signalization)
NOTE LED indicators are numbered from the left.

13.6.11 Light Indicators

Indicator
Go Indicator
►
Constantly lit
►
Flashing
Fault Indicator
►
Constantly lit
►
Flashing
13.6.12 Technical Specifications
Specification
i-Drive wheel diameter
Max. fast forward speed (flat ground, loaded)
Max. forward speed (flat ground, loaded)
Max. reverse speed (flat ground, loaded)
Max. angle of ascent
Noise level (when retracting the drive wheel)
13.6.13 Electrical specification
Specification
Accumulator Voltage
Maximum Power Input
Fuse Accumulator fuse
D9U001MC5-0101_08
LED1
LED2
Off
Off
Off
Off
Off
Off
Off
On
Off
On
Off
On
Off
On
On
Off
On
Off
On
Off
On
Off
Meaning
Hand is on touch sensor; drive wheel is ready for use.
Hand is not on touch sensor; i-Drive is not ready for use.
i-Drive cannot be activated (i-Drive wheel is not lowered, castor
control lever is braked, bed is connected to the mains).
System is faulty (indicated on accumulator status indicator, see
service manual)
-or-
i-Drive control box heat protection is activated
Value
8,27 in.
4,43 Km/h (±15%)
2,16 Km/h (±15%)
2,16 Km/h (±15%)
6°
65 dB
Value
36 V DC, Capacity: 12 Ah
300 W
pipe fuse T 3.15 A
MDP 030 (30 A)
LED3
LED4
Off
On
On
Off
On
On
Off
Off
Off
On
On
Off
On
On
Off
Off
Off
On
On
Off
On
On
53
