1.9 Definitions

Basic Bed Configuration
Bed Weight
Clearance of Undercarriage
Duty Cycle
Ergoframe
Maximum Patient Weight
Safe Working Load
Siderail Height
Standard Bed Position
Adult
12
the pricelist model configuration, not including a mattress
The value depends on the product configuration, accessories or customer
adjustments.
the height from the floor to the lowest point of the undercarriage between
the castors, for the manipulation of accessories under a braked bed in the
standard position
cycle of operation of the motor: time of activity/time of rest
Ergoframe is the kinematic system of Mattress support platform Adjustment
whose effect is the elimination of pressure on the patient´s abdomen and pel-
vic area and frictional forces on the patient's back and legs.
Maximum Patient Weight depends on the application environment according
to IEC 60601-2-52. For application environment 1 (intensive/critical care) and
2 (acute care) reduce Safe working Load by 65 kg. For application environ-
ment 3 (long-term care) and 5 (ambulatory care) reduce Safe working Load
by 35 kg.
the highest allowable load on the bed (patient, mattress, accessories and the
load supported by those accessories)
the height of the upper crossbar or the edges of the siderails (not the highest
point of the siderail controls) from the patient surface
■ The height of the patient surface with regard to the floor is 400 mm
■ The mattress support platform, including the individual parts, has to be in a
horizontal (level - 0°) position.
■ The siderails are always locked in the upper position.
■ The basic position of the integrated extension.
Patient having a physical size equal to or more than 146 cm, a mass equal
to or more than 40 kg and a body mass index (BMI) equal to or more than 17
(according to IEC 60601-2-52).
