13.6.7 i-Drive Power Activation/Deactivation

Fig. i-Drive mains switch
To activate the i-Drive Power:
1. Check, if the mains switch of i-Drive Power is activated (1).
2. Press the Activation button ON located on the activation panel. The i-Drive wheel will lower and the green indicator
will flash.
To deactivate the i-Drive Power:
1. Retract the i-Drive wheel using the Retraction button located on the activation panel.
2. Deactivate the i-Drive using the mains switch (1).
Emergency i-Drive Power wheel retraction:
1. Press any GO button on the bed.
2. Deactivate the i-Drive using the mains switch (1).
3. Press the emergency retraction button (2).
NOTE Use emergency retraction in case of accumulator discharge or drive malfunction to move the bed to a safe area manually
without using i-Drive Power.

13.6.8 Free Drive

The i-Drive motor is equipped with free drive, which is active after pressing the forwards (7 or 8) or backwards (9) buttons (until
user holds the touch sensor area).
Free Drive is deactivated and the brake is activated when the direction of motion is changed. This is feature for lowering the risks
when going to a slope.

13.6.9 Accumulator

Fig. Accumulator indicator levels
To charge the accumulator:
► Connect the bed main cable to mains power.
► i-Drive will be charged (with the accumulator discharged, the charging may take up to 9 hours).
NOTE Accumulator charge values are just informational. Accumulator life is reduced when the accumulator is allowed to dis-
charge
completely.
52
Accumulator charge status:
1. While this indicator is flashing, the accumulator is critically dis-
charged.
2. 50%
3. 75%
4. 100% - the accumulator is charged
