14.2 Active Mattress (not integrated)

WARNING!
Follow instructions for use of a compatible active mattress carefully!
CAUTION!
Risk of material damage due to an incorrect fixation of compatible active mattress on the mattress support
platform!
► Adjust the bed to maximum Cardiac Chair Position before fixing all the straps of the inflated mattress to the
mattress support platform!
Installation instructions:
► Remove any existing mattress.
► Observe mattress dimensions and its orientation before putting it on the Mattress support platform.
► Place SCU on the foot board of the bed or on the floor.
Fig. Bottom of Active Mattress (not integrated)

14.3 Symbioso (integrated mattress)

WARNING!
Follow instructions for use of the Symbioso integrated mattress replacement system carefully!
CAUTION!
Risk of material damage due to an incorrect fixation of compatible integrated mattress on the mattress supp-
ort platform!
► Adjust the bed to maximum Cardiac Chair Position before fixing all the straps of the inflated mattress to the
mattress support platform!
WARNING!
Symbioso mattress are compatible with System Control Units delivered by manufacturer only!
► Do not use any other System Control Units with Symbioso mattress!
CAUTION!
Material damage due to incorrect installation of SCU!
► If the SCU does not come factory-fitted, have it installed by a service engineer authorised by LINET ®.
