15.2 Infusion Stands

WARNING!
Risk of injury due to use of incorrect accessories or because of incorrect use!
Infusion Stands must only be used for their intended use. Always read the instructions for use!
► Only mount an infusion pump to the lower (wider) telescopic section of an infusion stand above the head board/
foot board.
► Never mount an infusion pump to the upper (thiner) telescopic section of an infusion stand.
► Ensure the infusion pump will not collide with any movable parts of the bed (especially backrest part) or with the
patient. This must be verified during installation.
► Do not over tighten the infusion pump clamps during fitment. Over tightening may damage the infusion stand.
► Infusion pump can be only used if the infusion stand is fitted in the accessory holder socket in the head end on
the undercarriage of the bed.
► Do not use the infusion stand as driving/pushing device during the bed transport.
Infusion stands can be fitted to the head and foot board by either fitting into the IV/Infusion sockets mounted on the bed or using
alternative accesory holder socket in the head end on the undercarriage of the bed.
► Use exclusively infusion stands with 4 hooks for
hanging IV bags or baskets for intravenous solutions.
► Ensure the infusion stand individual hook 2kg maxi-
mum Safe Working Load is not exceeded.
► Ensure the infusion stand 20kg maximum Safe
Working Load is not exceeded.
► The total maximum loading of the IV/Infusion poles
must not exceed 20 Kg (44.1lbs).

15.3 Stabilising Pads

Fig. Stabilising Pads
D9U001MC5-0101_08
Fig. Infusion Stand
The stabilising pads ensure a stable position of the patient during lateral tilt
in order to prevent extubation or disconnection of IV lines or other equip-
ment.
Stabilising pad set:
► 2 lateral arm pads
► 2 lateral leg pads
► 2 head pads
► 1 internal leg pad
Applying pads:
► Position the patient in the middle of the bed.
► Place lateral pads between patient and siderails.
► Attach head pads to arm pads with Velcro.
► Place internal pad between the patient's legs.
► Tilt mattress platform left and right by 30° to check if the patient's
position is stable.
► The position is stable if the patient does neither shift nor turn over.
Fig. Infusion Pump – Correct
Fitment
59
