System config
FortiGate-1000 Administration Guide
IP Load balancing according to IP address. If the cluster units are connected
using switches, select IP to distribute traffic to units in a cluster based on the
Source IP and Destination IP of the packet.
IP Port Load balancing according to IP address and port. If the cluster units are
connected using switches, select IP Port to distribute traffic to units in a
cluster based on the source IP, source port, destination IP, and destination
port of the packet.
Priorities of Heartbeat Device
Enable or disable HA heartbeat communication and set the heartbeat priority for each
interface in the cluster.
By default HA heartbeat communication is set for two interfaces. You can disable HA
heartbeat communication for either of these interfaces or enable HA heartbeat for
other interfaces. In most cases you can maintain the default heartbeat device
configuration as long as you can connect the heartbeat device interfaces together.
To enable HA heartbeat communication for an interface, enter a priority for the
interface. To disable HA heartbeat communication for an interface, delete the priority
for the interface.
The HA heartbeat priority range is 0 to 512. The interface with the highest priority
handles all HA heartbeat traffic. If this interface fails or becomes disconnected, the
interface with the next highest priority handles all HA heartbeat traffic.
The cluster units use the ethernet interfaces configured with HA heartbeat priorities for
HA heartbeat communication. The HA heartbeat communicates cluster session
information, synchronizes the cluster configuration, synchronizes the cluster routing
table, and reports individual cluster member status. The HA heartbeat constantly
communicates HA status information to make sure that the cluster is operating
properly.
You can enable heartbeat communications for physical interfaces, but not for VLAN
subinterfaces.
Enabling the HA heartbeat for more interfaces increases reliability. If an interface fails,
the HA heartbeat can be diverted to another interface.
HA heartbeat traffic can use a considerable amount of network bandwidth. If possible,
enable HA heartbeat traffic on interfaces only used for HA heartbeat traffic or on
interfaces connected to less busy networks.
Table 5: Default heartbeat device configuration
FortiGate model
FortiGate-1000
Change the heartbeat device priorities as required to control the interface that is used
for heartbeat traffic and the interface to which heartbeat traffic reverts if the interface
with the highest heartbeat priority fails or is disconnected.
01-28006-0009-20041105
Default heartbeat device
Port 3
Port 4/HA
Default priority
50
100
