Ldap Server List; Ldap Server Options - Fortinet FortiGate FortiGate-1000 Administration Manual

Users and authentication

LDAP server list

LDAP server options

FortiGate-1000 Administration Guide
The FortiGate unit supports LDAP protocol functionality defined in RFC2251 for
looking up and validating user names and passwords. FortiGate LDAP supports all
LDAP servers compliant with LDAP v3.
FortiGate LDAP support does not extend to proprietary functionality, such as
notification of password expiration, that is available from some LDAP servers.
FortiGate LDAP support does not supply information to the user about why
authentication failed.
Figure 116:LDAP server list
Create New Add a new LDAP server.
Server Name/IP The domain name or IP address of the LDAP server.
Port The port used to communicate with the LDAP server.
Common Name The common name identifier for the LDAP server. 20 characters maximum.
This is the
Identifier
Distinguished The distinguished name used to look up entries on the LDAP server. It
reflects the hierarchy of LDAP database object classes above the Common
Name
Name Identifier.
The Delete and Edit icons.
Figure 117:LDAP server configuration
Name Enter a name to identify the LDAP server.
Server Name/IP Enter the domain name or IP address of the LDAP server.
Server Port Enter the port used to communicate with the LDAP server.
By default LDAP uses port 389.
01-28006-0009-20041105
LDAP
239
