Installation - Enterasys Matrix 7GR4202-30 Hardware Installation Manual

Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes
Personal vorgenommen werden.
Read the Release Notes shipped with the DFE module to check for any exceptions to the supported features
and operation documented in this guide.
This chapter provides the instructions to install the 7GR4270-12, 7GR4202-30, 7GR4280-19, and
7KR4290-02 DFE modules, and optional Mini-GBICs and XENPAK interface modules.
Note: Unless otherwise noted, the installation instructions for the DFE modules apply to all DFE
modules.
Follow the order of the sections listed below to correctly install the DFE module.
For information about...
Required Tools
Unpacking the DFE Module
Installing Optional Network Expansion Modules (NEMs)
Installing Optional Mini-GBICs
Installing an Optional XENPAK Module
Backplane Connections and Installation Rules
Installing Module into Matrix E7 or N7 Chassis
Installing Module into Matrix N3, N1, or N5 Chassis
Connecting to the Network
Connecting to COM Port for Local Management
Completing the Installation
Important Notice
Matrix DFE-Diamond Series Installation Guide 3-1
3

Installation

Refer to page...
3-2
3-2
3-2
3-3
3-6
3-8
3-10
3-12
3-13
3-20
3-24
