Summary of Contents for Enterasys 5G1XX
- Page 1 MATRIX E5 Series Modules (5H1xx and 5G1xx) Local Management User’s Guide 9033583-01...
- Page 3 Enterasys Networks and its licensors reserve the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
- Page 4 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between You, the end user, and Enterasys Networks, Inc. (“Enterasys”) that sets forth your rights and obligations with respect to the Enterasys software program (“Program”) in the package.
- Page 5 UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Product (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227-19 (a) through (d) of the Commercial Computer Software-Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers.
-
Page 7: Table Of Contents
Figures ...ix Tables...xi ABOUT THIS GUIDE Using This guide ... xiii Structure of This Guide ... xiii Related Documents...xv Document Conventions...xv Typographical and Keystroke Conventions...xvi Getting Help ... xvii INTRODUCTION Overview ... 1-1 1.1.1 1.1.2 Navigating Local Management Screens ... 1-3 Local Management Requirements ... - Page 8 802.1Q VLAN Current Table Information ... 7-29 7.14 802.1Q VLAN Static Table Configuration... 7-30 Contents Displaying System Information ... 5-2 Displaying Switch Version and Module Information... 5-4 IP Configuration ... 6-4 IP Connectivity Test (Ping) ... 6-6 HTTP Configuration ... 6-7 Configuring Community Names ... 6-12 Configuring IP Trap Managers...
- Page 9 Displaying the Unicast Address Table ... 8-6 Displaying the IP Multicast Registration Table... 8-8 SYSTEM RESTART MENU SCREEN Resetting the System ... 9-1 Logging Off the system ... 9-2 CONFIGURING AND MONITORING THE SWITCH 10.1 Common Tasks ... 10-1 10.2 Setting Password Protection ... 10-2 10.3...
- Page 10 11.2.1 11.2.2 11.2.3 11.2.4 11.2.5 11.2.6 11.3 Enterasys Proprietary MIB Extensions... 11-4 11.4 Compiling MIB Extensions: Enterasys Website ... 11-4 SPANNING TREE CONCEPTS General ...A-1 A.1.1 Spanning Tree Protocol in a Network ...A-2 Spanning Tree Protocol Parameters...A-3 A.3.1 A.3.2 A.3.3 A.3.4 A.3.5 A.3.6...
-
Page 11: Figures
Password Screen ... 3-4 Main Menu... 4-2 System Information Menu Screen ... 5-1 System Information Screen ... 5-2 Switch Information Screen ... 5-4 Management Setup Menu Screen... 6-2 Network Configuration Menu Screen ... 6-3 IP Configuration Screen ... 6-4 IP Connectivity Test Screen ... 6-6 HTTP Configuration Screen ... - Page 12 Port Statistics Screen ...8-2 RMON Statistics Screen ...8-4 Unicast Address Table Screen ...8-7 IP Multicast Registration Table Screen...8-8 System Restart Menu Screen...9-1 Spanning Tree Using Switches... A-2 Example of Multi-Switch VLAN Configuration... B-3 Class of Service Example... C-2 Figures Page...
- Page 13 Table VT Terminal Setup...2-3 Factory Default Settings ... 3-5 SmartTrunk, Ports Associated with Group IDs ... 7-21 10-1 SmartTrunk Configuration, Ports Associated with Group IDs...10-12 Spanning Tree Protocol Defaults... A-3 Tables Page Tables...
-
Page 15: About This Guide
Management screens to monitor and manage 5H1xx and 5G1xx modules, attached segments, in a five-slot 5C105 chassis. Only the 5H1xx and 5G1xx modules can operate in the 5C105 chassis. Depending on the firmware version used in the module, some features described in this document may not be supported. -
Page 16: Main Menu
Chapter 10, Configuring and Monitoring the and operating the switch using the Local Management (LM) screens. The LM screens allow you to modify the default switch settings and configure the switch for network management. The LM screens also allow you to monitor the switch performance and status. -
Page 17: Related Documents
The protocol’s mechanisms allow a host to inform its local router that it wants to receive transmissions addressed to a specific multicast group. RELATED DOCUMENTS The following Enterasys Networks document may help to set up, control, and manage the module: • 5C105 MATRIX E5 Overview and Setup Guide... -
Page 18: Typographical And Keystroke Conventions
Typographical and Keystroke Conventions TYPOGRAPHICAL AND KEYSTROKE CONVENTIONS bold type Bold type can denote either a user input or a highlighted screen selection. ENTER Indicates either the ENTER or RETURN key, depending on your keyboard. Indicates the keyboard Escape key. SPACE bar Indicates the keyboard space bar key. -
Page 19: Getting Help
GETTING HELP For additional support related to this product or document, contact Enterasys Networks using one of the following methods: World Wide Web http://www.enterasys.com Phone (603) 332-9400 Internet mail support@enterasys.com ftp://ftp.enterasys.com Login anonymous Password your email address To send comments or suggestions concerning this document, contact the Enterasys Networks Technical Writing Department via the following email address: TechWriting@enterasys.com... -
Page 21: Introduction
LM keyboard conventions. Depending on the firmware version used in the switch module, some features described in this document may not be supported. Refer to the Release Notes shipped with the switch module to determine which features are supported. -
Page 22: The Management Agent
Out-of-band network management passes data along a medium that is entirely separate from the common data carrier of the network, for example, a cable connection between a terminal and a switch module COM port. Enterasys Networks’ Local Management is an out-of-band network management system. -
Page 23: Navigating Local Management Screens
You can also access Local Management using a Telnet connection through one of the network ports of the switch module. NOTE: For details on the setup parameters for the console, how to connect a console to the switch module, or how to make a telnet connection, refer to Chapter Introduction... -
Page 25: Local Management Requirements
2.1.1 Console Cable Connection Use the Console Cable Kit provided with the switch module to attach the management terminal to the switch module COM port as shown in (Section 2.1), which describes how to make a terminal connection 2.2), which provides guidelines on how to make a Telnet connection... -
Page 26: Management Terminal Setup Parameters
To connect the switch module to a PC or compatible device running the VT terminal emulation, proceed as follows: 1. Connect the RJ45 connector at one end of the cable (supplied in the kit) to the COM port on the switch module. - Page 27 VT100, 7 Bit Controls VT100ID Normal Cursor Keys UPSS DEC Supplemental 2400, 4800, 9600, 19200 (Recommended setting is 9600, which is the default when the switch boots up.) Receive=Transmit XOFF at 64 8 bits No Parity 1 Stop Bit No Local Echo...
-
Page 28: Telnet Connections
IP address, subnet mask, and default gateway using an out-of-band connection or the BOOTP protocol. Once the switch module is configured, you can establish a Telnet session from any TCP/IP based node on the network. Telnet connections to the switch module require the community name passwords assigned in the SNMP Configuration screen. -
Page 29: Accessing Local Management
3.4. Depending on the firmware version used in the switch module, some features described in this document may not be supported. Refer to the Release Notes shipped with the switch module to determine which features are supported. NAVIGATING LOCAL MANAGEMENT SCREENS The switch module Local Management application consists of a series of menu screens. -
Page 30: Local Management Screen Hierarchy
Port Statistics RMON Statistics Unicast Address Table IP Multicast Registration Table System Restart Menu Exit Accessing Local Management System Information Switch Information Network Configuration Network Configuration IP Configuration Menu Menu IP Connectivity Test (Ping) Serial Port Configuration HTTP Configuration SNMP Configuration... -
Page 31: Accessing Local Management Screens
ACCESSING LOCAL MANAGEMENT SCREENS Access to the Local Management screens menus is gained by connecting a terminal to the console port through a direct cable connection or over a modem, or using Telnet to access the Local Management over the network as detailed in module, as well as to monitor its status and performance. -
Page 32: Password Screen
“public,” with no passwords. The administrator has Read/Write access, which allows you to read and modify switch information. The guest has Read Only access to the management program, which allows you to view switch information, but not modify any operating parameters. -
Page 33: Factory Defaults
NOTE: A user is allowed three attempts to enter the correct password; on the third failed attempt, the current connection is terminated. FACTORY DEFAULTS Table 3-1 lists the default settings for switch configuration parameters. Each parameter can be changed via the console menus or Telnet. Table 3-1 Factory Default Settings Parameter... - Page 34 Table 3-1 Factory Default Settings (Continued) Parameter Spanning Tree Algorithm Active Aging Time Bridge Priority Forward Delay Hello Time Max Age Path Cost Port Priority Spanning Tree Protocol System Configuration Password Screen Time-out Send Authentication Fail Traps SNMP Community Names Terminal Baud Rate User Name Virtual LANs...
-
Page 35: Main Menu Screens
Main Menu Screens Once you have logged into Local Management, the Main Menu screen is the first screen to display. This chapter describes the Main Menu screen, introduces the screens that you can use to obtain system operating information, change operating parameters, obtain module operating statistics, reset and exit Local Management. -
Page 36: Main Menu
Figure 4-1 Main Menu Selection System Information Menu (For details, refer to System Information Switch Information Main Menu Screens Description Chapter Provides basic system description, including contact information. Shows hardware/firmware version numbers, power status, and expansion modules used in the chassis. - Page 37 Displays operational status, including link state, flow control method, and duplex mode. Enables Spanning Tree Algorithm; also sets parameters for hello time, maximum message age, switch priority, and forward delay; as well as port priority and path cost. Displays full listing of parameters for the Spanning Tree Algorithm.
- Page 38 Displays detailed statistical information for the selected port such as packet type and frame size counters. Provides full address listing, as well as search and clear functions. Displays all the multicast groups active on this switch, including multicast IP addresses and corresponding VLAN IDs. Chapter Restarts system with options to use POST, or to retain factory defaults, IP settings, or user authentication settings.
-
Page 39: System Information Menu Screens
Use the System Information Menu screen (Figure 5-1) described below to access the System Information and Switch Information screens to display a basic description of the switch, including contact information, and hardware/firmware versions. Figure 5-1 System Information Menu Screen System Information Menu Screens... -
Page 40: System Information Screen
System Information Switch Information 5.1.1 Displaying System Information Use the System Information screen information about the switch, or for quick system identification. Figure 5-2 System Information Screen System Information Menu Screens Description Provides basic system description, including system object ID, up time, name, contact, and location. - Page 41 Maximum string length is 99, but the screen only displays 45 characters. You can use the arrow keys to browse the whole string. Description System hardware description. MIB II object identifier for switch is network management subsystem. Length of time the current management agent has been running. (Note that the first value is 1/100 seconds.) Name assigned to the switch system.
-
Page 42: Switch Information Screen
5.1.2 Displaying Switch Version and Module Information Use the Switch Information screen hardware/firmware version numbers, serial number and slot number it occupies in the chassis. Figure 5-3 Switch Information Screen Parameter Description Hardware Version Hardware version of the main board. -
Page 43: Management Setup Menu Screens
Management Setup Menu Screens The Management Setup Menu screen provides access to the screens used to set up the console communications parameters and specify the switch IP address, passwords to Local Management screens, and switch SNMP configuration. After initially logging onto the system, perform the following: •... -
Page 44: Management Setup Menu Screen
MANAGEMENT SETUP MENU SCREEN The menu items provided by the Management Setup Menu screen following sections. Figure 6-1 Management Setup Menu Screen Selection Network Configuration Menu Serial Port Configuration SNMP Configuration Menu Console Login Configuration Management Setup Menu Screens Description Provides access to two screens to perform functions that include IP setup, Ping facility, HTTP (Web Agent) setup, Telnet configuration, and MAC address. -
Page 45: Network Configuration Menu Screen
CHANGING THE NETWORK CONFIGURATION Use the Network Configuration Menu screen • Access the screens needed to set the bootup option. • Configure the switch’s Internet Protocol (IP) parameters. • Enable the on-board Web Agent. • Set the number of concurrent Telnet sessions allowed. -
Page 46: Ip Configuration
The screen shown below is described in the following table. Figure 6-3 IP Configuration Screen Management Setup Menu Screens Description Used to set the bootup option, or configure the switch’s IP parameters. Used to test IP connectivity (Ping) to a specified device. Used to enable the Web Agent. - Page 47 BOOTP reply has been received. BOOTP requests will be periodically broadcast by the switch in an effort to learn its IP address. (BOOTP values can include the IP address, default gateway, subnet mask, TFTP boot file name, and TFTP server IP.)
-
Page 48: Ip Connectivity Test Screen
6.2.2 IP Connectivity Test (Ping) Use the IP Connectivity Test screen reached. The screen parameters are described in the following table. Figure 6-4 IP Connectivity Test Screen Parameter IP Address Test Time Interval Success/Failure [Start] command Management Setup Menu Screens (Figure 6-4) to see if another site on the Internet can be Description... -
Page 49: Http Configuration Screen
6.2.3 HTTP Configuration Use the HTTP Configuration screen specify the TCP port that will provide HTTP service. The screen shown below is described in the following table. Figure 6-5 HTTP Configuration Screen Parameter HTTP Server HTTP Port Number Changing the Network Configuration (Figure 6-5) to enable/disable the on-board Web agent, and to Description... -
Page 50: Serial Port Configuration Screen
Configuring the Serial Port CONFIGURING THE SERIAL PORT You can access the on-board configuration program by attaching a VT100 compatible device to the switch’s COM port. (For more information on connecting to this port, refer to Chapter 2.) The communication parameters for this port can be accessed from the Serial Port Configuration screen (Figure 6-6) shown below and described in the following table. - Page 51 Parameter Default Management CONSOLE Mode MODE Baud rate 9600 Data bits 8 bits Stop bits 1 bit Parity NONE Time-Out (in minutes) Auto Refresh (in seconds) Description Indicates that the console port settings are for direct console connection. The rate at which data is sent between devices. Options: 2400, 4800, 9600, and 19200 bps.
-
Page 52: Snmp Configuration Menu Screen
Access rights to the on-board agent are controlled by community strings. To communicate with the switch, the NMS must first submit a valid community string for authentication. The options for configuring community strings and related trap functions are described in the following sections. - Page 53 SNMP access based on specified strings. For details, refer Section 6.4.1. Provides access to the IP Trap Managers screen to specify the management stations that will receive authentication failure messages or other trap messages from the switch. For details, refer to Section Management Setup Menu Screens 6.4.2.
-
Page 54: Snmp Communities Screen
6.4.1 Configuring Community Names The SNMP Communities screen screen. The table following the figure describes the fields. This screen is used to configure the community strings authorized for management access. Up to 5 community names may be entered. Figure 6-8 SNMP Communities Screen Parameter Community Name Access... -
Page 55: Ip Trap Managers Screen
The IP Trap Managers screen The table following the figure describes the fields. This screen is used to specify the management stations that will receive authentication failure messages or other trap messages from the switch. Up to 5 trap managers may be entered. -
Page 56: Console Login Configuration Screen
Administrator as soon as possible, and store it in a safe place. (If for some reason your password is lost, or you cannot gain access to the System Configuration Program, contact Enterasys Networks for assistance.) The parameters shown on this screen are indicated in the following figure and table. -
Page 57: Startup Configuration Screen
If the module fails and you need to run the diagnostics, change the position of dip switch 5 (on the Mode Switch Bank) on the board and reboot the module. This changes the startup paramenter to ENABLED and forces the diagnostics to run when the module is rebooted. -
Page 58: Downloading System Software
Before downloading an image to the device, copy the image to the network TFTP server. A new firmware image file must be a file from Enterasys Networks; otherwise the agent will not accept it. The success of the download operation depends on the accessibility of the TFTP server and the quality of the network connection. -
Page 59: Tftp Download Screen
Figure 6-12 TFTP Download Screen Parameter Download Server IP Agent Software Upgrade Download Filename Download Mode Description IP address of a TFTP server. A community specified for trap management access. The binary file to download to the agent module. Downloads to permanent flash ROM. Management Setup Menu Screens 6-17... - Page 60 TFTP server to a switch module. The configuration file must be one that was uploaded to the TFTP server from a switch module of the same model with the same optional hardware, and running firmware revision 1.03.xx or higher.
-
Page 61: Device Control Menu Screens
This chapter describes the Device Control Menu screen and the screens that can be selected from its menu to control a broad range of functions. Screen Navigation Path Password > Main Menu > Device Control Menu CONFIGURING THE SWITCH The Device Control Menu screen (Figure 7-1) is used to control a broad range of functions, including port configuration, Spanning Tree support for redundant switches, port mirroring, multicast filtering, and VLANs. -
Page 62: Device Control Menu Screen
Displays current port settings and port status. For details, refer to Section 7.3. Configures the switch, its ports and modules to participate in a local Spanning Tree. For details, refer to Displays the current Spanning Tree configuration for the switch, its ports and modules. For details, refer to Section 7.5. - Page 63 Section 7.8. Displays/configures extended bridge capabilities provided by this switch, including support for traffic classes, and VLAN extensions. For details, refer to Used to configure the default port priorities and queue assignments for each port, or to display the mapping for the traffic classes.
-
Page 64: Port Configuration Screen
Configuring Port Parameters CONFIGURING PORT PARAMETERS Use the Port Configuration screen (Figure 7-2) to set or display communication parameters for any port or module on the switch. Figure 7-2 Port Configuration Screen Device Control Menu Screens... - Page 65 “blocking” traffic from end stations or segments connected directly to the switch when its buffers fill. Back pressure is used for half duplex and IEEE 802.3x for full duplex. Do not use flow control if a port is connected to a hub.
-
Page 66: Port Information Screen
Viewing the Current Port Configuration VIEWING THE CURRENT PORT CONFIGURATION The Port Information screen (Figure 7-3) displays the port type, status, link state, and flow control in use, as well as the communication speed and duplex mode. To change any of the port settings, use the Port Configuration menu. - Page 67 Shows the flow control type in use. Flow control can eliminate frame loss by “blocking” traffic from end stations connected directly to the switch. Back pressure is used for half duplex and IEEE 802.3x for full duplex. Note that flow control should not be used if a port is connected to a hub.
-
Page 68: Spanning Tree Configuration:selection Menu Screen
This allows the switch to interact with other bridging devices (that is, an STA-compliant switch, bridge or router) in your network to ensure that only one route exists between any two stations on the network. The Spanning Tree... -
Page 69: Sta Bridge Configuration Screen
7.4.1 Configuring STA Bridge The STA Bridge Configuration screen following table describes the STA Bridge configuration parameters. Figure 7-5 STA Bridge Configuration Screen Parameter Default Spanning Tree ENABLED Protocol Priority 32768 (Figure 7-5) to set the STA Bridge parameters. The Description Enables this parameter to participate in an STA compliant network. - Page 70 Parameter Default Hello Time (in seconds) Max Age (in seconds) Forward Delay (in seconds) 7-10 Device Control Menu Screens Description Time interval at which the root device transmits a configuration message. The minimum value is 1. The maximum value is the lower of 10 or [(Max.
-
Page 71: Sta Tree Port Configuration Screen
Shows 10/100TX, 100FX, 1000LX or 1000SX port. Defines the priority for the use of a port in the STA algorithm. If the path cost for all ports on a switch are the same, the port with the highest priority (i.e., lowest value) will be configured as an active link in the spanning tree. - Page 72 Parameter Default Cost 100/19/4 Fast Forwarding ENABLED 7-12 Device Control Menu Screens Description This parameter (path cost) is used by the STA to determine the best path between devices. Therefore, lower values should be assigned to ports attached to faster media, and higher values assigned to ports with slower media.
-
Page 73: Spanning Tree Information: Selection Menu Screen
VIEWING THE CURRENT SPANNING TREE CONFIGURATION The Spanning Tree Information: Selection Menu screen two screens to display a summary of the STA information for the overall bridge or for a specific port. To make changes to the STA bridge or STA port operating parameters, refer back to Section 7.4. -
Page 74: Sta Bridge Information Screen
7.5.1 Displaying the Current STA Bridge The STA Bridge Information screen Bridge. The following table describes the parameters shown on the screen. Figure 7-8 STA Bridge Information Screen Parameter Priority Hello Time (in seconds) Max Age (in seconds) 7-14 Device Control Menu Screens (Figure 7-8) displays the current information about the STA Description... - Page 75 The priority and MAC address of the device in the spanning tree that this switch has accepted as the root device. The path cost from the root port on this switch to the root device. The number of the port on this switch that is closest to the root.
-
Page 76: Sta Port Information Screen
Viewing the Current Spanning Tree Configuration 7.5.2 Displaying the Current STA for Ports or Modules The parameters shown in the following STA Port Information screen (Figure 7-4) and table are for port STA Information (Ports 1-12, Ports 13-24, Ports 25-36, or Ports 37-48). NOTE: The actual number of ports varies depending on the module. - Page 77 A port on a network segment with no other STA compliant bridging device is always forwarding. • If two ports of a switch are connected to the same segment and there is no other STA device attached to this segment, the port with the smaller ID forwards packets and the other is blocked.
-
Page 78: Mirror Port Configuration Screen
The priority and number of the port on the designated bridging device through which this switch must communicate with the root of the spanning tree. (Figure 7-10) to designate a single port pair (source and... -
Page 79: Configuring Smarttrunks
• Ports can only be assigned to one trunk. • The ports in a trunk must belong to the same switch chip (refer to • The ports at both ends of a connection must be configured as trunk ports. •... -
Page 80: Smarttrunking Configuration Screen
Use the Smart Trunking Configuration screen Figure 7-11 SmartTrunking Configuration Screen Parameter SmartTrunk Group SmartTrunk Logical Port SmartTrunk Status SmartTrunk Group ID Port 7-20 Device Control Menu Screens (Figure 7-11) to set up port trunks. Description Read only field that indicates the SmartTrunk Group number associated with the logical ports listed under SmartTrunk Logical Port. -
Page 81: Igmp Multicast Filtering
SmartTrunk Priotocol NO CHANGE field SAVE SHOW The ports used for each trunk must all be on the same internal switch chip, which is synonymous with the SmartTrunk Group ID. Table 7-1 SmartTrunk, Ports Associated with Group IDs Group IDs... -
Page 82: Configuring Igmp
CONFIGURING IGMP This protocol allows a host to inform its local switch/router that it wants to receive transmissions addressed to a specific multicast group. Use the IGMP Configuration screen configure multicast filtering. Figure 7-12 IGMP Configuration Screen NOTE: The default values are shown in... -
Page 83: Extended Bridge Configuration Screen
VLAN Learning mode, use the Extended Bridge Configuration screen Figure 7-13 Extended Bridge Configuration Screen Description The time in minutes that must elapse before the switch removes the port from an IGMP group. This timer is started after the number of queries are missed as defined in the IGMP Query Count. - Page 84 VLAN ID used in frame tags) and its egress status (VLAN-Tagged or Untagged) on each port. For details, refer Section 7.15. This switch does not support multiple local bridges (that is, multiple Spanning Trees). Allows you to select the VLAN Learning mode (IVL or SVL) used by the switch.
-
Page 85: P Configuration Menu Screen
Configuring Traffic Classes 7.10 CONFIGURING TRAFFIC CLASSES IEEE 802.1p defines up to 8 separate traffic classes. This switch supports Quality of Service (QoS) by using two priority queues, with weighted fair queuing for each port. You can use the 802.1P... -
Page 86: P Port Priority Configuration Screen
7.10.2 802.1P Port Traffic Class Information This switch provides two priority levels with weighted fair queuing for port egress. This means that any frames with a default or user priority from 0~3 are sent to the low priority queue “0” while those from 4~7 are sent to the high priority queue “1”... -
Page 87: P Port Traffic Class Information Screen
User Priority 7.11 CONFIGURING VIRTUAL LANs You can use the VLAN configuration menu to assign any port on the switch to any of up to 1024 LAN groups. In conventional networks with routers, broadcast traffic is split up into separate domains. -
Page 88: Q Vlan Base Information Screen
Device Control Menu Screens (Figure 7-17) displays basic information on the Description The VLAN version used by this switch as specified in the IEEE 802.1Q standard. Maximum VLAN ID recognized by this switch. Maximum number of VLANs that can be configured on this switch. -
Page 89: Q Vlan Current Table Information Screen
7.13 802.1Q VLAN CURRENT TABLE INFORMATION This screen shows the current port members of each VLAN and whether or not the port supports VLAN tagging. Ports assigned to a large VLAN group that crosses several switches should use VLAN tagging. However, if you just want to create a small port-based VLAN for one or two switches, you can assign ports to the same untagged VLAN (refer to configuration is shown in Figure... -
Page 90: Q Vlan Static Table Configuration
VLAN. You can add/delete port members of any VLAN in the switch. (Also, note that all ports can only belong to one untagged VLAN. This is set to VLAN 1 by default, but can be changed via the 802.1Q VLAN Port Configuration screen described in Section 7.15.) -
Page 91: Q Vlan Static Table Configuration Screen
Figure 7-19 802.1Q VLAN Static Table Configuration Screen Parameter VLAN Name Status Egress Ports Forbidden Egress Ports Untagged Ports Description The ID for the VLAN currently displayed. Range: 1-2048 A user-specified symbolic name for this VLAN. String length: Up to 8 alphanumeric characters Sets the current editing status for this VLAN as: Not in Service, Destroy, or Active. -
Page 92: Q Vlan Port Configuration Screen
Parameter [Show] [More] [New] 7.15 802.1Q VLAN PORT CONFIGURATION Use the 802.1Q VLAN Port Configuration screen for IEEE 802.1Q VLAN features. Figure 7-20 802.1Q VLAN Port Configuration Screen 7-32 Device Control Menu Screens Description Displays settings for the specified VLAN. Displays consecutively numbered VLANs. - Page 93 The VLAN ID assigned to untagged frames received on this port. Use the PVID to assign ports to the same untagged VLAN. This switch accepts “All” frame types, including VLAN tagged or VLAN untagged frames. Note that all VLAN untagged frames received on this port are assigned to the PVID for this port.
-
Page 94: Static Unicast Address Table Configuration Screen
7-34 Device Control Menu Screens (Figure Description The VLAN group to which this port is assigned. The MAC address of a host device attached to this switch. The port to which the host device is attached. 7-21) to manually configure... - Page 95 The status for an entry can be set to: Permanent–This entry is currently in use and will remain so after the next reset of the switch. DeleteOnReset–This entry is currently in use and will remain so until the next reset.
-
Page 97: Network Monitoring Menu Screens
This chapter describes the Network Monitor Menu screen and the screens that can be selected from its menu. Screen Navigation Path Password > Main Menu > Network Monitor Menu MONITORING THE SWITCH The Network Monitor Menu screen (Figure 8-1) provides access to port statistics, RMON statistics, IP multicast addresses, and the static (unicast) address table. -
Page 98: Port Statistics Screen
Error statistics on the traffic passing through each port are also displayed. This information can be used to identify potential problems with the switch (such as a faulty port or unusually heavy loading). The values displayed have been accumulated since the last system reboot. - Page 99 Parameter Alignment Errors FCS Errors Single Collision Frames* Multiple Collision Frames* SQE Test Errors* Deferred Transmissions* Late Collisions Excessive Collisions* Internal Mac Transmit Errors* Carrier Sense Errors* Frames Too Long Internal Mac Receive Errors* The reported values will always be zero because these statistics are not supported by the internal chip set.
-
Page 100: Rmon Statistics Screen
DISPLAYING RMON STATISTICS Use the RMON Statistics screen module from RMON group 1. (RMON groups 2, 3 and 4 can only be accessed using SNMP management software such as NetSight.) The following screen displays the overall statistics on traffic passing through each port. RMON statistics provide access to a broad range of statistics, including a total count of different frame types and sizes passing through each port. - Page 101 Parameter Received Frames Broadcast Frames Multicast Frames CRC/Alignment Errors Undersize Frames Oversize Frames Fragments Jabbers Collisions 64 Byte Frames Description The total number of frames (bad, broadcast and multicast) received. The total number of good frames received that were directed to the broadcast address.
-
Page 102: Displaying The Unicast Address Table
Parameter 65-127 Byte Frames 128-255 Byte Frames 256-511 512-1023 1024-1518 Byte Frames Refresh Statistics command Reset Counters command DISPLAYING THE UNICAST ADDRESS TABLE The Unicast Address Table contains the MAC addresses and VLAN identifier associated with each port (that is, the source port associated with the address and VLAN), sorted by MAC address or VLAN ID. -
Page 103: Unicast Address Table Screen
Figure 8-4 Unicast Address Table Screen Parameter Aging Time Dynamic Counts Static Counts Port Status Displaying the Unicast Address Table Description Time-out period in seconds for aging out dynamically learned forwarding information. Range: 10 - 65534 seconds; Default: 300 seconds The number of dynamically learned addresses in the table. -
Page 104: Ip Multicast Registration Table Screen
[Clear All] DISPLAYING THE IP MULTICAST REGISTRATION TABLE Use the IP Multicast Registration Table screen active on this switch, including multicast IP addresses and the corresponding VLAN ID. Figure 8-5 IP Multicast Registration Table Screen Network Monitoring Menu Screens Description Displays the address table based on specified VLAN ID, and sorted by primary key MAC or VID. - Page 105 Description VLAN ID assigned to this multicast group. IP address for specific multicast services. The switch ports registered for the indicated multicast service. Indicates if the ports were learned dynamically or via IGMP. Displays the address table sorted on VID and then Multicast Scrolls through the entries in the address table.
-
Page 107: System Restart Menu Screen
System Restart Menu Screen This chapter describes the System Restart Menu screen and how to reset the switch or exit a current Local Management session. Screen Navigation Path Password > Main Menu > System Restart RESETTING THE SYSTEM Select the System Restart Menu item in the Main Menu screen to reset the management agent. The... -
Page 108: Logging Off The System
LOGGING OFF THE SYSTEM To log off the system, use the Exit command in the Main Menu screen to exit the configuration program and terminate communications with the switch for the current session. Refer to Section 4-1 for information about the Main Menu screen. -
Page 109: Configuring And Monitoring The Switch
(Section 10.2) • Assigning an IP address for the switch if you plan to manage the switch using SNMP, or if you use Telnet to access the switch • Checking network configuration status and verifying that network connections are correct (Section 10.4) -
Page 110: Setting Password Protection
When you configure the password parameter, the factory default setting is deactivated and the new password governs access to the console menus. If you forget your password, contact your Enterasys Networks Support Representative. NOTE: You are automatically logged out from the console menus based on the Lock-out Time setting in the Console Login Configuration Menu. -
Page 111: Assigning An Ip Address
Link for the port reads DOWN. 4. If you see a DOWN status for a connected port, plug the cable into another port on the switch or try another cable. -
Page 112: Viewing Switch Statistics
The switch can send SNMP messages called traps to SNMP management stations when an important event occurs with the switch. The switch allows up to five destinations to be configured for these trap messages to be sent. To configure SNMP access for the switch, proceed as follows: 1. -
Page 113: Downloading A Software Upgrade
You can upgrade the operational software in the switch without physically opening the switch or being in the same location. The software storage sector in the flash memory of the switch is reprogrammed, allowing you to easily download software feature enhancements and problem fixes to the switch from a local or remote location. -
Page 114: Downloading Via Tftp
To perform a TFTP download, you must first configure the switch. This consists of programming the switch with an IP address, if this has not already been done, and entering the IP address of the TFTP server and the name of the upgrade file. -
Page 115: Configuring Spanning Tree Parameters
1. Select the Device Control Menu from the Main Menu. 2. Select the Spanning Tree Configuration Menu and then STA Bridge Configuration. 3. Turn the switch Spanning Tree operation on or off by setting the Spanning Tree Protocol field to ENABLED. -
Page 116: Configuring Class Of Service
This switch uses IGMP (Internet Group Management Protocol) to query for any attached hosts who want to receive a specific multicast service. The switch looks up the IP Multicast Group used for this service and adds any port which received a similar request to that group. It then propagates the service request on to any neighboring multicast switch/router to ensure that it will continue to receive the multicast service. -
Page 117: Configuring Port Operation
Default is DISABLED. 4. Set the IGMP Query Count to the number of minutes that must elapse before the switch removes the port from an IGMP group. This timer is started after the number of queries are missed as defined in the IGMP Query Count. -
Page 118: Configuring The Unicast Address Table
There are seven types of status that can be configured for each address in the table: • Permanent, which means that the MAC address is in use and will remain so after the next switch reset. •... -
Page 119: Port Locking
1. From the Network Monitor Menu, select Static Unicast Address Table Configuration. 2. For the MAC address, specify the VLAN ID, switch port, and the Status (Permanent, Delete On Reset, Lock Port, Unlock Port, Invalid, Delete On Time Out, or Other). -
Page 120: Setting A Default Gateway
The default Gateway parameter defines the IP address of a router or other network device to which IP packets are to be sent if destined for a subnet outside of that which the switch is operating. To set a default gateway, proceed as follows: 1. -
Page 121: Configuring Smarttrunk S
This allows the traffic passing across that link to be automatically distributed to the other links in the trunk, without losing any significant amount of traffic. Configuring and Monitoring the Switch 10-13... -
Page 123: Snmp Management
Managed entities supporting SNMP typically contain software, which runs locally on the device and is referred to as an agent. The software in the switch functions as an agent, monitoring and controlling the functionality of the switch. -
Page 124: Mib Objects
RFC 1213 provides management of system-level parameters, including TCP/IP protocol-related statistics, IP addressing, and interface statistics for each switch port. MIB II is the standard MIB defined by RFC 1213. All agent devices operating SNMP are required to support at least part of MIB II. -
Page 125: Rfc 1493 (Bridge Mib)
11.2.5 RFC 1757 (RMON MIB) RFC 1757 is a group defined under MIB II. This MIB provides management for the RMON aspects of the switch. The switch supports four of the nine groups of RMON defined for Ethernet networks on a per port basis. -
Page 126: Ieee 802.1Q (Q Mib)
This MIB provides management for the VLAN aspects of the switch. 11.3 ENTERASYS PROPRIETARY MIB EXTENSIONS Areas of switch functionality not covered by the standard RFC MIBs are specified in the Enterasys private MIB. This MIB definition is specified separately from MIB II. Areas covered in this MIB include various system, switch, and port level information. -
Page 127: Spanning Tree Concepts
A.1.1 Spanning Tree Features The switch meets the requirements of the Spanning Tree Protocol (STP) by BEING ABLE TO performing the following functions: • Create a single spanning tree from any arrangement of switching or bridging elements. -
Page 128: Spanning Tree Protocol In A Network
A and B goes down, the link between A and C becomes active, thereby establishing a path between A and B through switch C. Additionally, if the connection between B and C goes down, the link between A and C becomes active, establishing a path between B and C through switch A. -
Page 129: Spanning Tree Protocol Parameters
SPANNING TREE PROTOCOL PARAMETERS Several configuration parameters control the operation of the Spanning Tree Protocol. describes the parameters and lists the switch default settings for each parameter. NOTE: You can cause serious network performance degradation if you do not fully understand Spanning Tree concepts. -
Page 130: Spanning Tree Protocol Operation
Table A-1 Spanning Tree Protocol Defaults (Continued) Parameter Description Cost The Spanning Tree Protocol calculates and ensures that an Component of active topology generates minimal cost paths. A value of Each Port 100 is generally used for 10 Mbps Ethernet networks, a value of 19 for 100 Mbps Fast Ethernet, and a value of 4 for 1000 Mbps Gigabit Ethernet. -
Page 131: Handling Duplicate Paths
A.3.5 Handling Duplicate Paths When the active topology of the network is determined, all packets between any two nodes in the network use only one path. Where a duplicate path exists, the non-designated port is put into a blocking state. A.3.6 Remapping Network Topology If there is a change in the network topology due to a failure or the removal or addition of any active... -
Page 133: Virtual Lans (Vlans)
VLANs provide greater network efficiency by reducing broadcast traffic, but also allow you to make network changes without having to update IP addresses or IP subnets. VLANs inherently provide a high level of network security, since traffic must pass through a Layer 3 switch or a router to reach a different VLAN. -
Page 134: Vlan Configuration
VLANs. However, if you want a port on this switch to participate in one or more VLANs, but the device at the other end of the link does not support VLANs, then you must add this port as an untagged port (that is, a port attached to a VLAN-unaware device). -
Page 135: Forwarding Tagged/Untagged Frames
FORWARDING TAGGED/UNTAGGED FRAMES Ports can be assigned to multiple tagged or untagged VLANs. Each port on the switch is therefore capable of passing tagged or untagged frames. To forward a frame from a VLAN-aware device to a VLAN-unaware device, the switch first decides where to forward the frame, and then strips off the VLAN tag. -
Page 137: Class Of Service
• normal As traffic enters the switch, it is assigned to one of the two priority levels according to information located in the 802.1Q header tag of the frame (refer to port number. Frames are then placed into one of two transmit queues on the outbound switch port based on their priority level. -
Page 138: C-1 Class Of Service Example
The tagged header in the frame governs individual frame priority. Figure C-1 shows priority queuing operating within a switch. Frames entering the switch through ports 1 and 4 are tagged as normal traffic and placed in a normal priority queue on the outbound port. -
Page 139: Ip Multicast Filtering
A router, or multicast-enabled switch, can periodically ask their hosts if they want to receive multicast traffic. If there is more than one router/switch on the LAN performing IP multicasting, one of these devices is elected “querier”... - Page 141 Auto-negotiation, configuration of Class of Service operation of Class of Service, configuration of community names, SNMP 10-3 Configuring and monitoring the switch assigning the IP address 10-3 checking the network configuration status common tasks involved in configuration of port operation...
