MGBIC-08 Specifications (1000BASE-ELX)

Table A-9 MGBIC-08 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Maximum Input Power
Link Power Budget
1. The maximum drive distance (up to 70 km) depends on the quality of the installed single-mode fiber-optic
cable segment. Use the Link Power Budget to calculate the maximum cable length of the attached segment.
The Link Power Budget must not exceed those specified in this table. The MGBIC-08 input power must not
exceed -3 dBm. Otherwise, saturation could occur.
Table A-10 MGBIC-08 Operating Range
Item
9 or 10 µm SMF

MGBIC-02 Specifications (1000BASE-T)

Table A-11 MGBIC-02 / Specifications
Item
Supported Cable
Type:
Maximum Length
Connector
Data Rate
TX Output impedance
RX Input impedance
-0 dBm, min.
-24 dBm, min.
-3 dBm
1
(Full Duplex Only) 23 dB
1550 nm
N/A
Specification
Copper, Category 5 UTP
Up to 100 meters
RJ45
1 Gbps, IEEE 802.3:2000 compatible
1000BASE-T operation only
Automatic crossover detection
100 ohms, typical at all frequencies between 1 MHz and 125 MHz
100 ohms, typical at all frequencies between 1 MHz and 125 Hz
Gigabit Ethernet Specifications
+2 dBm, typical
-26 dBm, typical
28dB, typical
Range
70,000 Meters
