This appendix provides information about the following:
For information about...

DFE Module Specifications

Mini-GBIC Input/Output Specifications
Gigabit Ethernet Specifications
10GBASE XENPAK PHY Specifications
COM Port Pinout Assignments
Regulatory Compliance
Enterasys Networks reserves the right to change the specifications at any time without notice.
DFE Module Specifications
Table A‐1 provides the I/O ports, processors and memory, physical, and environmental module
specifications for the 7GR4270‐12, 7GR4202‐30, 7GR4280‐19, and 7KR4290‐02 DFE modules.
Unless noted differently, the specifications apply to all four DFE modules.
Table A-1 Specifications
Item
7GR4270-12 Ports
Ports 1 through 12
7GR4202-30 Ports
Ports 1 through 30
7GR4280-19 Ports
Ports 1 through 18
Option Slot
Specification
Twelve fixed Mini-GBIC slots for up to twelve mix-and-match
1000BASE-SX and -LX compliant Mini-GBICs. Refer to
"Mini-GBIC Input/Output Specifications" on page A-3 for a list of
the supported Mini-GBICs.
Thirty, 10BASE-T/100BASE-TX/1000BASE-T compliant ports via
RJ45 connectors.
Mini-GBIC slots for up to 18 mix-and-match 1000BASE-SX, -LX,
-ELX and 1000BASE-T compliant Mini-GBICs. Refer to
"Mini-GBIC Input/Output Specifications" on page A-3.
Supports one optional network expansion module.
Matrix DFE-Diamond Series Installation Guide A-1
A

Specifications

Refer to page...
A-1
A-3
A-3
A-6
A-7
A-7
