Completing the Installation
Completing the DFE module installation depends on if the module is being installed in:
• a new DFE module system (refer to "Completing the Installation of a New System" on
page 3‐25), or
• an established, operating DFE module system (refer to "Completing the Installation of a DFE
Module in an Existing System" on page 3‐26).
3-24 Installation
VT Series Port Adapter Wiring and Signal Diagram
DB25
Conductor Pin
Red 2
Blue 3
Yellow 5
Green 7
Orange 20
Modem Port Adapter Wiring and Signal Diagram
DB25
Conductor Pin
Blue 2
Orange 8
Red 3
Green 7
Yellow 20
Gray 22
Signal
Transmit (TX)
Receive (RX)
Clear to Send (CTS)
Ground (GRD)
Data Terminal Ready
Signal
Transmit (TX)
Data Carrier Detect (DCD)
Receive
Ground (GRD)
Data Terminal Ready (DTR)
Ring Indicator
