10GBASE XENPAK PHY Specifications

10GBASE XENPAK PHY Specifications
At the time of printing of this manual, there are four 10GBASE XENPAK modules available.
Tables A‐12 through A‐14 provide the specifications for each XENPAK module.
Table A-12 XENPAK Port, Physical, and Environmental Specifications
Item
Port
One Port
Physical
Dimensions
Approximate Weight
Environmental
Operating Temperature
Storage Temperature
Operating Relative Humidity
Table A-13
Table A-13 XENPAK Fiber-Optic Specifications
XENPAK PHY
10GBASE-LR
10GBASE-ER
10GBASE-LX4
10GBASE-SR
Table A‐14 provides you with the necessary information to make decisions concerning the cable
type, maximum length, and connector type according to each XENPAK module.
Table A-14 Recommended Cable Types and Specifications
XENPAK PHY
10GBASE-LR
10GBASE-ER
10GBASE-LX4
10GBASE-SR
1. The 10GBASE-ER XENPAK requires a minimum of 5 dB attenuation or a cable length of about 10 km.
A-6 Specifications
provides you with the input/output specifications for each version of XENPAK.
Output Power
<0.5 dBm
<4.0 dBm
<0.5 dBm
<-1 dBm
Type
SMF
1
SMF
SMF
MMF
62.5 um MMF 200Mhz/km
50 um MMF 400Mhz/km
50 um MMF 2000Mhz/km
Specification
Port interface that can support a full 10 Gbps throughput.
11.33 H x 3.48 W x 1.17 D (cm)
4.46 H x 1.37 W x 0.46 D (in.)
Net: 0.13 kg (0.29 lbs)
5° to 40° C (41° to 104° F)
-30° to 73° C (-22° to 164° F)
-30° to 73° C (-22° to 164° F)
5% to 90% (non-condensing)
Extinction Received
Ratio Sensitivity
>4 dB -10.28 dBm
>3 dB -10.3 dBm
>3.5 dB -10.3 dBm
-13.4 dBm
(on 10μm fiber)
>3 dB -11.1 dBm
Max. Length
10 km (6.21 mi)
40 km (24.85 mi)
10 km (6.21 mi)
300 m (984.25 ft)
33 m (108 ft)
66 m (217 ft)
300 m (884 ft)
Link Budget
0 to 9.4 dB
5 to 11 dB
0 to 7.5 dB
0 to 8.2 dB
(on 10μm fiber)
7.3 dB
Connector
SC
SC
SC
SC
SC
SC
