This guide provides an overview, installation and troubleshooting instructions, and specifications
for the Enterasys Matrix
modules, Mini‐GBIC interface cards, and XENPAK interface modules.
For information about the CLI (Command Line Interface) set of commands used to configure and
manage the DFE modules, refer to the Enterasys Matrix DFE‐Diamond/Platinum Series Configuration
Guide.

Who Should Use This Guide

This guide is intended for a network administrator responsible for installing and setting up the
DFE modules.
®
DFE‐Diamond 7GR4270‐12, 7GR4202‐30, 7GR4280‐19, and 7KR4290‐02
Note: In this guide, the following terms are used:
• DFE refers to Distributed Forwarding Engine series of modules.
• DFE module or module refers to the 7GR4270-12, 7GR4202-30, 7GR4280-19, or
7KR4290-02. If the information applies only to one of the modules, the module is referred to by
its model number (such as 7GR4270-12).
• Network expansion module or NEM refers to an optional uplink card installed on the main logic
board and accessible through the option slot of the 7GR4280-19.
• Mini-GBIC (Mini-Gigabit Interface Card) refers to a smaller optional interface card that plugs
into a NEM or the 7GR4270-12 or 7GR4280-19 port slots.
• XENPAK PHY refers to a type of physical interface module that plugs into the 7KR4290-02.
Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes
Personal vorgenommen werden.

About This Guide

Matrix DFE-Diamond Series Installation Guide xiii
