Mode Switch Settings and Installing Options
This appendix covers the following items:
For information about...

Required Tools

Setting the Mode Switches

Memory Locations and Replacement Procedures
Required Tools
Use the following tools to perform the procedures provided in this appendix:
• Antistatic wrist strap
• Phillips screwdriver
Setting the Mode Switches
Figure B‐3 through Figure
normal operation. These switches are set at the factory and rarely need to be changed.
Switch definitions and positions are as follows:
• Switches 1 through 6 – For Enterasys Networks use only.
Caution: An antistatic wrist strap is required to perform the procedures in this appendix. Use the
antistatic wrist strap to minimize ESD damage to the devices involved.
Precaución: Para llevar a cabo los procedimientos especificados en el apéndice deberá utilizar
una pulsera antiestática. Esta pulsera sirve para minimizar los efectos de las descargas de
electricidad estática.
Caution: Read the appropriate sections to be fully aware of the consequences when changing
switch settings.
Only qualified personnel should change switch settings.
Precaución: Si desea modificar la configuración del interruptor, lea las secciones correspondientes
para saber cuál será el resultado de hacerlo.
Estas modificaciones a la configuración sólo debe realizarlas personal calificado.
B‐5 show the location of the mode switches and the switch settings for
Refer to page...
Matrix DFE-Diamond Series Installation Guide B-1
B
B-1
B-1
B-3
