Memory Locations and Replacement Procedures
Figure B-5
1 DRAM SIMM
Figure B-6
1 Flash DIMM
B-4 Mode Switch Settings and Installing Options

DIMM and DRAM SIMM Locations for 7GR4270-12 and 7GR4202-30

2 Flash DIMM

DIMM and DRAM SIMM Locations for 7GR4280-19

2 DRAM SIMM
➂
➀ ➁
3 Main PC board (7GR4270-12 is shown)
3 Main PC board
