General

3.1

Revision

Revision
1.0
1.1
1.2
1.3
1.4
3.2

Introduction

The operating instructions below describe the commissioning and functionality of the field bus interface
BUSINTX11 in combination with specific field busses. The interface is intended for operation on digital
power sources in the PHOENIX (MIG/MAG) or TETRIX (TIG) machine series. Separate interfaces are
available for both power source systems. A BUSINTX11 for a PHOENIX system does not have the same
functionality as a BUSINTX11 for a TETRIX system. These are two different interfaces which cannot be
used interchangeably! An interface designed for a TETRIX system does not function on a PHOENIX
power source.
The BUSINTX11 has numerous options for actuation, and these are supported in full by the PC300
welding parameter software. It is advisable to use the PC300 software to set up the BUSINTX11
wherever possible.
3.3

System overview

The table below gives an overview of the interfaces currently available in relation to the welding systems:
Field bus
CANopen
CAN DeviceNet
Interbus FSMA
Interbus Rugged Line
Profibus
(1)
Only in the switching cabinet variant
Item No.: 099-008225-EWM01
Date Change
26.02.2006 Draft version
04.08.2006 Official instructions
23.08.2006 Addition of profiles, overview of interfaces, TETRIX functionality
23.01.2007 Support for the Profibus DP module
27.07.2009 Addition of profiles and functions to the software version
042-00897-00002 or 042-00926-00002
PHOENIX TETRIX
(1)
X X
(1)
X X
(1)
X X
(1)
X X
(1)
X X
