EWM BUSINT X11 Operating Instructions Manual page 110

Profiles for TETRIX TIG and plasma systems
Profile on the Interbus Module
Actuation data
Byte Bit no.
no.
1 3
1 4
1 5
1 6
1 7
2 0-3
4-6
2 7
3 0-7
4 0-7
5 0-7
6 0-7
7 0-7
8-11 0-7
110
Function
Start auxiliary process
Bit allocation:
0
1
Error reset
User-defined output
Bit allocation:
0
1
Job mode
Bit allocation:
0
1
Welding simulation
Bit allocation:
0
1
Program number specification
Reserved
WF switching (optional)
Bit allocation:
0
1
JOB number specification
I specification, low-byte
I specification, high-byte
WF cold wire specification,
low byte
WF cold wire specification,
high byte
Reserved
Description
Start signal for the auxiliary process (plasma)
Auxiliary process off
Auxiliary process on
Acknowledgement signal for system error
Switches the user-defined relay output on the bus
module
Relay not switched
Relay switched
Signal activates the JOB mode function
JOB mode switched off
JOB mode active
Activates the Simulate Welding function
Simulation active
Simulation off
Select a program number in the range 0-15
Switches between 2 wire drive units
WF case 1 is active
WF case 2 is active
Select a JOB number in the range of
1-255
Specification of the welding current, the scaling is
always 100% dependent on the system current in
question:
Range: 0 to 0 x 7FFF
0 corresponds to RANGE-MIN
0 x 7FFF corresponds to the max. system current
Specify the wire speed in program 0
Specification of the wire value
Range: 0 to 0 x 7FFF
0 corresponds to 0.0 m/min
0 x 7FFF corresponds to 10.0 m/min or 5.00 m/min
depending on the cold wire feed
Specifies the wire value in program 0
