Process data
Byte Bit no.
no.
8 0-7
9 0-7
10 0-7
Item No.: 099-008225-EWM01
Profiles for PHOENIX MIG/MAG systems
Function
Actual motor current value
high byte
Actual motor current value
low byte
Monitoring
Bit allocation:
0
1
2
3
4-7
Profiles for the Profibus DP module
Description
Current actual value for the motor current from the
wire feed system
Range: 0 to 0x7FFF
corresponds to 0.0A to 25.5A
Current actual value for the motor current from the
wire feed system
Bit field for displaying alarm messages during
welding parameter monitoring
Status =0, no alarm
Status =1, alarm
Welding voltage
Welding current
Wire-feed speed
WF motor current
Reserved
