The following data with 8 bytes are assigned to connection 2 (input 2):
Process data
Byte Bit no.
no.
0 0-7
1 0-7
2 0-7
3 0-7
4 0-7
5 0-7
6 0-7
7 0-7
Item No.: 099-008225-EWM01
Profiles for PHOENIX MIG/MAG systems
Function
Actual welding voltage value,
low byte
Actual welding voltage value,
high byte
Actual welding current value,
low byte
Actual welding current value,
high byte
Actual wire feed speed value ,
low byte
Actual wire feed speed value ,
high byte
Actual motor current value
low byte
Actual motor current value
high byte
Profiles for the CAN DeviceNet module
Description
Current actual value for the welding voltage
Range: 0 to 0 x 7FFF
corresponds to 0.0 V to 100.0 V
Current actual value for the welding voltage
Current actual value for the welding current
Range: 0 to 0 x 7FFF
corresponds to 0 A to 1000 A
Current actual value for the welding current
Current actual value for the wire feed speed
Range: 0 to 0 x 7FFF
corresponds to 0.0 m/min to 40.0 m/min
Current actual value for the wire feed speed
Current actual value for the motor current from the
wire feed system
Range: 0 to 0 x 7FFF
corresponds to 0.0 A to 25.5 A
Current actual value for the motor current from the
wire feed system
