Profiles for PHOENIX MIG/MAG systems
Profiles for the CAN DeviceNet module
The following data with 4 bytes are assigned to connection 1 (input 1):
Process data
Byte
Bit no.
no.
0
0
0
1
0
2
0
3
0
4
0
5
0
6
0
7
1
0-7
2
0-7
56
Function
I > 0
Bit allocation:
0
1
Ready for welding
Bit allocation:
0
1
Sticking
Bit allocation:
0
1
Error
Bit allocation:
0
1
Collision signal
Bit allocation:
0
1
Main current signal
Bit allocation:
0
1
Process active
Bit allocation
0
1
Reserved
Error
Monitoring
Bit allocation:
0
1
2
3
4-7
1 to 3 on bits 0 to 2
Input 3 is not available with
the seam tracking option
Description
"Current flows" signal from process
No current flowing
Current flows, arc stationary
Ready signal from process
System not ready
System is ready
Wire sticking message from process
Wire is free
Wire sticks to the workpiece
General fault message from process
No error
Fault occurred and not rectified
Signals triggering of the collision protection
No collision
Collision
Displays the status of the program sequence
Process is outside the main current phase
Process running in the main program
Signals the completion of the welding process
Process ended (after gas post-flows)
Process running
Error number of an error which has occurred
Bit field for displaying alarm messages during
welding parameter monitoring
Status = 0, no alarm
Status = 1, alarm
Welding voltage
Welding current
Wire feed speed
WF motor current
Reserved
Item No.: 099-008225-EWM01
