Profiles for TETRIX TIG and plasma systems
Profiles for the Profibus/Interbus module
Rx-PDO 1
Byte Bit no.
no.
0 7
1 0
1 1
1 2
1 3
1 4
1 5
2 0-3
4-7
3 0-7
Process data
Byte Bit no.
no.
0 0
0 1
0 2
0 3
102
Cob ID = 200h + address
Function
Error reset
Bit allocation:
0
1
Start auxiliary process
Bit allocation:
0
1
User-defined output
Bit allocation:
0
1
Welding simulation
Bit allocation:
0
1
Reserved
WF switching (optional)
Bit allocation:
0
1
Reserved
Program number specification
Not allocated
JOB number specification
Function
I > 0
Bit allocation:
0
1
Ready for welding
Bit allocation:
0
1
Sticking
Bit allocation:
0
1
Error
Bit allocation:
0
1
Description
Acknowledgement signal for system error
Signal must have positive edge for
acknowledgement
Start signal to initiate the auxiliary process
Auxiliary process is shut down
Auxiliary process is started
Switches the user-defined relay output
On the bus module
Relay not switched
Relay switched
Welding simulation switched off
Welding simulation activated
Switches between 2 wire drive units
WF case 1 is active
WF case 2 is active
Select a program number in the range 1-15
Select a JOB number in the range of
1-255
Description
"Current flows" signal from process
No current flowing
Current flows, arc stationary
Ready signal from process
System not ready
System is ready
Wire sticking message from process
Wire is free
Wire sticks to the workpiece
General fault message from process
No error
Fault occurred and not rectified
