EWM BUSINT X11 Operating Instructions Manual page 103

Process data
Byte Bit no.
no.
0 4
0 5
0 6
0 7
1 0-7
2 0-7
3 0-2
4 0-7
5 0-7
6 0-7
7 0-7
8 0-7
9 0-7
10 0-7
11 0-7
Item No.: 099-008225-EWM01
Profiles for TETRIX TIG and plasma systems
Function
Collision signal
Bit allocation:
0
1
Main current signal
Bit allocation:
0
1
Process active
Bit allocation
0
1
I > 0 Auxiliary process
Bit allocation:
0
1
Error
Not used
User-defined inputs
1 to 3 on bits 0 to 2
Actual welding voltage value,
low byte
Actual welding voltage value,
high byte
Actual welding current value,
low byte
Actual welding current value,
high byte
Actual wire feed speed value ,
low byte
Actual wire feed speed value ,
high byte
Actual motor current value
low byte
Actual motor current value
high byte
Profiles for the Profibus/Interbus module
Description
Signals triggering of the collision protection
No collision
Collision
Displays the status of the program sequence
Process is outside the main current phase
Process running in the main program
Signals the completion of the welding process
Process ended (after gas post-flows)
Process running
"Current flows" signal from auxiliary process
No current flowing
Current flowing, auxiliary process active
Error number of an error which has occurred
Signal status of the digital input
Logic:
0 V signal on the input = signal low
24 V on the input = signal high
Current actual value for the welding voltage
Range: 0 to 0 x 7FFF
corresponds to 0.0 V to 100.0 V
Current actual value for the welding voltage
Current actual value for the welding current
Range: 0 to 0 x 7FFF
corresponds to 0 A to 1000 A
Current actual value for the welding current
Current actual value for the wire feed speed
Range: 0 to 0 x 7FFF
corresponds to 0.0 m/min to 40.0 m/min
Current actual value for the wire feed speed
Current actual value for the motor current from the
wire feed system
Range: 0 to 0 x 7FFF
corresponds to 0.0 A to 25.5 A
Current actual value for the motor current from the
wire feed system
