Profiles for PHOENIX MIG/MAG systems
Profiles for the CAN DeviceNet module
Actuation data
Byte Bit no.
no.
1 2
1 3
1 4
1 5
1 6
1 7
2 0-3
2 7
3 0-7
4 0-7
5 0-7
6 0-7
7 -
8 0-7
9 -
50
Function
Reverse inching
Bit allocation:
0
1
WF switching (optional)
Bit allocation:
0
1
Error reset
User-defined output
Bit allocation:
0
1
Job mode
Bit allocation:
0
1
Welding simulation
Bit allocation:
0
1
Program number specification Select a program number in the range 0-15
Specification of master power
source with TANDEM
systems (optional)
Bit allocation:
0
1
JOB number specification
WF specification, low-byte
WF specification, high-byte
Correction specification,
low byte
Correction specification,
high byte
Dynamics specification,
low byte
Dynamics specification,
high byte
Description
Signal for reverse wire inching function
Reverse inching off
Reverse inching on
Switches between 2 wire drive units
WF case 1 is active
WF case 2 is active
Acknowledgement signal for system error
Switches the user-defined relay output on the bus
module
Relay not switched
Relay switched
Signal activates the JOB mode function
JOB mode switched off
JOB mode active
Activates the Simulate Welding function
Simulation active
Simulation off
Activates the master/slave power source in a
TANDEM system
System adopts slave function
System adopts master function
Select a JOB number in the range of
1-255
Specify the wire speed in program 0
Range: 0 to 0 x 7FFF
0 corresponds to WF-MIN
0 x 7FFF corresponds to 25.0 m/min
Specify the wire speed in program 0
Specify the voltage correction in program 0
Range: 0 to 255
0 corresponds to -10.0 V
0 x 4000 corresponds to 0 V
0 x 7FFF corresponds to +10.0 V
Specify the voltage correction in program 0
Specifies the dynamic in program 0
Range: 0 to 0 x 7FFF
0 corresponds to -40
0 x 4000 corresponds to 0
0 x 7FFF corresponds to +40
Specifies the dynamic in program 0
