Profiles for PHOENIX MIG/MAG systems
Profiles for the Profibus DP module
Process data
Byte Bit no.
no.
0 0
0 1
0 2
0 3
0 4
0 5
0 6
0 7
1 0-7
2 0-7
3 0-7
4 0-7
5 0-7
6 0-7
60
Function
Error
Bit allocation:
0
1
User-defined input 1
Process active
Bit allocation
0
1
I > 0
Bit allocation:
0
1
Collision signal
Bit allocation:
0
1
Ready for welding
Bit allocation:
0
1
Main current signal
Bit allocation:
0
1
Fusing
Bit allocation:
0
1
Error
Actual welding voltage value,
high byte
Actual welding voltage value,
low byte
Actual welding current value,
high byte
Actual welding current value,
low byte
Actual wire feed speed value,
high byte
Description
General fault message from process
No error
Fault occurred and not rectified
Signal status of the digital input
Logic:
0V signal on the input = signal low
24V on the input = signal high
Indicates the completion of the welding process
Process ended (after gas post-flows)
Process running
Current-flows signal from process
No current flowing
Current flows, arc stationary
Signals the triggering of the collision protection
Collision or transmitter not connected
No collision
Ready signal from process
System not ready
System is ready
Displays the status of the program sequence
Process is outside the main current phase
Process running in the main program
Wire fusion message from process
Wire is free
Wire is fused onto the workpiece
Error number of an error which has occurred
Current actual value for the welding voltage
Range: 0 to 0x7FFF
corresponds to 0.0V to 100.0V
Current actual value for the welding voltage
Current actual value for the welding current
Range: 0 to 0x7FFF
corresponds to 0A to 1000A
Current actual value for the welding current
Current actual value for the wire feed speed
Range: 0 to 0x7FFF
corresponds to 0.0m/min to 40.0m/min
