EWM BUSINT X11 Operating Instructions Manual page 85

The data can only be assigned to a single connection in this profile.
Process data
Byte Bit no.
no.
0 0
0 1
0 2
0 3
0 4
0 5
0 6
0 7
1 0-7
2 0-7
3 0-2
4 0-7
5 0-7
6 0-7
Item No.: 099-008225-EWM01
Profiles for TETRIX TIG and plasma systems
Function
I > 0
Bit allocation:
0
1
Ready for welding
Bit allocation:
0
1
Sticking
Bit allocation:
0
1
Error
Bit allocation:
0
1
Collision signal
Bit allocation:
0
1
Main current signal
Bit allocation:
0
1
Process active
Bit allocation
0
1
I > 0 Auxiliary process
Bit allocation:
0
1
Error
Not used
User-defined inputs
1 to 3 on bits 0 to 2
Actual welding voltage value,
low byte
Actual welding voltage value,
high byte
Actual welding current value,
low byte
Profiles for the CAN DeviceNet module
Description
"Current flows" signal from process
No current flowing
Current flows, arc stationary
Ready signal from process
System not ready
System is ready
Wire sticking message from process
Wire is free
Wire sticks to the workpiece
General fault message from process
No error
Fault occurred and not rectified
Signals triggering of the collision protection
No collision
Collision
Displays the status of the program sequence
Process is outside the main current phase
Process running in the main program
Signals the completion of the welding process
Process ended (after gas post-flows)
Process running
"Current flows" signal from auxiliary process
No current flowing
Current flowing, auxiliary process active
Error number of an error which has occurred
Signal status of the digital input
Logic:
0 V signal on the input = signal low
24 V on the input = signal high
Current actual value for the welding voltage
Range: 0 to 0x 7FFF
corresponds to 0.0 V to 100.0 V
Current actual value for the welding voltage
Current actual value for the welding current
Range: 0 to 0 x 7FFF
corresponds to 0 A to 1000 A
85
