11 Overview of plug configurations
11.1 X4, digital inputs
The control has 4 digital inputs with 24V logic. 24V switches the input logically high,
0V switches the input logically low.
Pin no.: Function/Meaning
X4/1 +24V
X4/2 Torch collision signal
X4/3 User-defined input
X4/4 0V
X4/5 User-defined input
X4/6 User-defined input
The inputs are not isolated.
Inputs 2 and 3 cannot be used in combination with the seam tracking option!
11.2

X5, digital outputs

The control has 2 floating relay contacts
Pin no.: Function/Meaning
X5/1 Make contact
X5/2 Break contact
X5/3 Foot contact relay
X5/4 Make contact
X5/5 Break contact
X5/6 Foot contact relay
The relays should not be loaded with significant inductive or capacitive loads.
The relay contacts are designed for 8A at 250V AC.
11.3

X7, analogue inputs

The control has 2 analogue inputs for rapid detection of actual process values:
Pin no.: Function/Meaning
X7/1 Reference +10V
X7/2 Uact, 0-10V (corresponds 0 to 100V) Actual welding voltage value
X7/3 Iact, 0-10V (corresponds 0 to
1000A)
X7/4 Reference 0V
128
Term in status data
Torch collision
User-defined input 1
User-defined input 2
User-defined input 3
Term in actuation data
Monitoring warning
Monitoring warning
Monitoring warning
User-defined output
User-defined output
User-defined output
Term in status data
Actual welding current value
