EWM BUSINT X11 Operating Instructions Manual page 45

Rx-PDO 1
Byte Bit no.
no.
1 4
1 5
1 6
1 7
2 0-7
3 0-3
4-6
7
4 0
Item No.: 099-008225-EWM01
Profiles for PHOENIX MIG/MAG systems
Cob ID = 200h + address
Function
Position search
Bit allocation:
0
1
Blow-out
Bit allocation:
0
1
Reserved
WF switching (optional)
Bit allocation:
0
1
JOB number specification
Program number specification
Not allocated
Welding simulation
Bit allocation:
0
1
Specification of master power
source with TANDEM
systems (optional)
Bit allocation:
0
1
Profiles for the CANopen module
Description
Activates the position search function for the
workpiece
Position search off
Position search on
Manual check via the blow-out valve
Blow-out valve off
Blow-out valve on
Switches over between two wire feed units
Wire feed unit 1 is active
Wire feed unit 2 is active
Select a JOB number in the range of
1-255
Select a program number in the range 0-15
Welding simulation switched off
Welding simulation activated
Activates the master/slave power source in a
TANDEM system
System adopts slave function
System adopts master function
45
