EWM BUSINT X11 Operating Instructions Manual page 32

Operative mode
Check-back of the process parameters
I
A
B
I > 0
C
D*
Legend
Description
Start signal
A
Main current
B
Process active
C
Ready for welding
D*
* From version 0.0.A.0 the signal can be used during the welding process.
32
P
start
P
A
Figure 5-2
P
end
Item No.: 099-008225-EWM01
t
t
t
t
t
t
t
t
