MODULE STATISTICS

The Module Statistics screen provides statistics and performance
information for the 6H122-08. For details about this screen, refer to
Section 5.25.
NETWORK TOOLS
The Network Tools function resides on the 6H122-08 and consists of a
series of commands that allow the user to access and manage network
devices. Section 5.29
5.14

MODULE CONFIGURATION MENU SCREEN

The Module Configuration Menu screen,
Local Management screens that allow you to configure and monitor
operating parameters, modify SNMP community names, set SNMP traps,
configure switch parameters and configure 6H122-08 ports.
The following menu items on the Module Configuration Menu
NOTE
screen may not display if the operational mode of the module
has been set to SECURE FAST VLAN:
SWITCH CONFIGURATION
SMARTTRUNK CONFIGURATION
Refer to your Release Notes to see if the functionality provided
by the above screens is supported in SECURE FAST VLAN
mode.
Section 5.15.9
mode.
Access the Module Configuration Menu screen from the Module Menu
screen by using the arrow keys to highlight the MODULE
CONFIGURATION menu item and pressing ENTER. The Module
Configuration screen displays.
6H122-08 User's Guide
Module Configuration Menu Screen
explains how to use the Network Tools utility.
provides instructions on setting the operational
Figure 5-17, provides access to
5-37
