Welcome to the Cabletron Systems 6H122-08 SmartSwitch 6000
Interface Module User's Guide. This guide describes the 6H122-08
Interface Module and provides information concerning network
requirements, installation, troubleshooting, and the use of Local
Management.
1.1

USING THIS GUIDE

Read through this guide completely to understand the 6H122-08 module
features, capabilities, and Local Management functions. A general
working knowledge of Fast Ethernet and IEEE 802.3 type data
communications networks and their physical layer components is helpful
when using these devices.
In this document, the 6H122-08 Interface Module is referred to
NOTE
as either the "6H122-08" or the "module".
1.2

STRUCTURE OF THIS GUIDE

This guide is organized as follows:
Chapter 1, Introduction, outlines the contents of this manual, describes
the features of the 6H122-08, and provides instructions for getting
additional help. This chapter also includes a list of technology and user
guides that may help the user to set up and manage the 6H122-08.
Chapter 2, Network
that must be met before installing the 6H122-08 into the 6C105
SmartSwitch 6000 chassis.
Chapter 3, Installation, provides instructions on how to install the
module in the chassis and connect segments to the device.
Chapter 4, Troubleshooting, details the 6H122-08 LANVIEW LEDs that
enable quick diagnosis of network/operational problems.
6H122-08 User's Guide
CHAPTER 1
INTRODUCTION
Requirements, outlines the network requirements
1-1
