This chapter provides information concerning the following:
• Using the LANVIEW diagnostic and status monitoring system
• Troubleshooting network and module operational problems
• Using the RESET button
4.1

USING LANVIEW

The 6H122-08 uses Cabletron Systems built-in visual diagnostic and
status monitoring system called LANVIEW. The LANVIEW LEDs
(Figure 4-1) allow quick observation of the network status to aid in the
diagnosing of network problems. Refer to
the LEDs.
For a functional description of the LANVIEW LED on the optional Fast
Ethernet Interface Module (FE-100TX), refer to
The terms flashing, blinking, and solid used in the LED
NOTE
definition tables of this chapter indicate the following:
Flashing indicates an irregular LED pulse.
Blinking indicates a steady LED pulse, (50% on/off).
Solid indicates a steady LED light. No pulsing.
6H122-08 User's Guide
CHAPTER 4
TROUBLESHOOTING
Table 4-1 for a description of
Section 4.2.
4-1
