Appendix C: Optional Installations and Mode Switch Bank Settings
C.3
INSTALLING OPTIONAL FAST ETHERNET
INTERFACE MODULES
Figure C-2
shows the location of the Fast Ethernet Interface Module
connectors on the 6H122-08 board for port slots 7 and 8.
Optional Fast
Ethernet Interface
Modules
Figure C-2 6H122-08 Fast Ethernet Interface Module Connector Location
C-4
Connectors
6H122-08 User's Guide
